[GW20K-SDT-30] GoodWe 20kW 3ph String Inverter

GoodWe 20kW 3ph String Inverter - Image 2

2 In Stock

GoodWe 20kW 3ph String Inverter

Login | Register to see price

GoodWe 20kW 3ph String Inverter

The GoodWe SDT G3 Series is a three-phase string inverter, designed for residential and small commercial systems with high-power PV modules. The SDT G3 inverters allow for high current input.

With up to 22 A maximum current input per string, the inverter is fully compatible with high-power modules.

It offers integrated safety features including AFCI (Arc-Fault Circuit Interruption) and optional Type II surge protection on both the AC and DC sides, ensuring enhanced electrical safety and lightning protection. With IP66 protection and a naturally cooled design, the SDT G3 operates quietly and efficiently, making it ideal for both indoor and outdoor installations.

Note: Pending for G98/G99/G100 Certificate

KEY FEATURES:

Maximum efficiency of 98.2%
Modern and compact design
Smart and silent operation
Increased yield (110% AC power)
2 MPPTs
Max. Input Current per MPPT: 32 / 22A
Optional AFCI 3.0 function
Smart energy management
IP66 protection
AFCI (optional)
DC Surge Protection Type III (Type II Optional)
Smart Fan Cooling
Integrated Remote Shutdown

[GW25K-ET] GoodWe 25kW 3Ph Hybrid Inverter with DC & AFCI (ET 15-30K)

GoodWe 25kW 3Ph Hybrid Inverter with DC & AFCI (ET 15-30K) - Image 2

2 In Stock

GoodWe 25kW 3Ph Hybrid Inverter with DC & AFCI (ET 15-30K)

Login | Register to see price

GoodWe 25kW 3Ph Hybrid Inverter with DC & AFCI (ET 15-30K)

The GoodWe ET 15–30 kW Series is a powerful three-phase hybrid inverter, designed for residential and commercial systems. The ET Series can be combined with a wide range of battery capacities and brands.

The ET Series also offers a powerful backup performance, capable of delivering up to 36 kVA for 60 seconds. This short-term overload capacity ensures stable operation of high-demand appliances during backup mode.

With integrated DC surge protection and AFCI (Arc-Fault Circuit Interruption), it ensures enhanced electrical safety and fire prevention. Its high-voltage battery interface and UPS-level backup capability ensure a seamless energy supply.

KEY FEATURES:

Maximum efficiency of 97.5%
Modern and compact design
Smart and efficient operations
Powerful back-up with UPS level switching
Parallel connection for larger systems
Peak shaving
IP66 protection
AFCI (optional)
DC Surge Protection Type II
Smart Fan Cooling
Integrated Remote Shutdown

[GW25K-SDT-30] GoodWe 25kW 3ph String Inverter

GoodWe 25kW 3ph String Inverter - Image 2

Check Availability

GoodWe 25kW 3ph String Inverter

Login | Register to see price

GoodWe 25kW 3ph String Inverter

The GoodWe SDT G3 Series is a three-phase string inverter, designed for residential and small commercial systems with high-power PV modules. The SDT G3 inverters allow for high current input.

It offers integrated safety features including AFCI (Arc-Fault Circuit Interruption) and optional Type II surge protection on both the AC and DC sides, ensuring enhanced electrical safety and lightning protection. With IP66 protection and a naturally cooled design, the SDT G3 operates quietly and efficiently, making it ideal for both indoor and outdoor installations.

Note: Pending for G98/G99/G100 Certificate

KEY FEATURES:

Maximum efficiency of 98.3%
Enhanced performance
Smart and silent operation
Increased yield (110% AC power)
3 MPPTs
Max. Input Current per MPPT: 40A
Optional AFCI 3.0 function
Smart energy management
IP66 protection
AFCI (optional)
DC Surge Protection Type II
Smart Fan Cooling
Integrated Remote Shutdown

[GW25K-SDT-30-AFCI] GoodWe 25kW SDT G3 3Ph String Inverter - 3 MPPTs, DC & AFCI

GoodWe 25kW SDT G3 3Ph String Inverter - 3 MPPTs, DC & AFCI - Image 2

Check Availability

GoodWe 25kW SDT G3 3Ph String Inverter - 3 MPPTs, DC & AFCI

Login | Register to see price

GoodWe 25kW SDT G3 3Ph String Inverter - 3 MPPTs, DC & AFCI

The SDT G3 25–40 kW series is purpose-built for three-phase commercial and industrial PV systems using modern high-power modules. It accepts high input currents, supports generous DC oversizing and delivers quiet, reliable operation thanks to its fanless, IP66 design.

Optional Type II SPDs on both AC and DC sides, together with Arc Fault Circuit Interrupter 3.0 (AFCI 3.0), raise site safety by detecting arc faults, sending alarms via monitoring and shutting the inverter down when needed.

Note: G99 ENA Certified, document pending

KEY FEATURES:

25 kW, 3-phase, 3 MPPTs for flexible rooftop layouts
AFCI 3.0 for enhanced DC safety with automatic arc detection, alarms and inverter shutdown
High current input for high-power PV modules
Max PV input voltage: 1100 V
European efficiency: up to 98.3%
Supports up to 150% DC oversizing
Supports 110% AC overloading for increased energy yield
Fanless, silent operation for C&I rooftops
IP66 enclosure for outdoor installation
Built-in DC switch
Optional Type II SPD on both DC and AC sides
Anti-islanding and grid protections integrated
Smart energy management
Communication: RS485, WiFi, LAN or 4G or Bluetooth (Optional)
Warranty: 5 Years

[GW2000-XS-30-AFCI] GoodWe 2kW XS G3 1Ph String Inverter - 1MPPT, DC & AFCI

GoodWe 2kW XS G3 1Ph String Inverter - 1MPPT, DC & AFCI - Image 2

3 In Stock

GoodWe 2kW XS G3 1Ph String Inverter - 1MPPT, DC & AFCI

Login | Register to see price

GoodWe 2kW XS G3 1Ph String Inverter - 1MPPT, DC & AFCI

The GoodWe XS G3 is a compact single-phase inverter for modern homes. It delivers high yields in a lightweight unit and is suitable for indoor or outdoor installation. It supports high-current modules up to 16 A and allows up to 110% AC output.

Natural convection keeps it quiet, and a low start-up voltage helps the inverter begin tracking earlier in the morning and stay online later as array voltage dips.

Quick commissioning via the GoodWe app, SEMS monitoring, smart-home and SG-ready (Smart Grid-ready) compatibility, export limiting, 24-hour load monitoring, and weather-resistant construction make it a reliable fit for single-phase residential systems.

KEY FEATURES:

2kW, single-phase string inverter with AFCI
Ultra-compact and lightweight (4.6 kg)
1 MPPT architecture for simple, cost-effective installs
Supports high-power modules with up to 16 A input current
Low start-up voltage (50V) - for higher energy harvest
European efficiency: 96.8%
10% additional power compared to the nominal output
Silent, fanless operation using natural convection cooling
App-based commissioning and remote monitoring via GoodWe SEMS
Smart home and SG-ready integration
Export-limiting compatibility for UK DNO requirements
IP66 enclosure for indoor or outdoor installation
Surge protection Type III (Type II optional)
Warranty: 10 years

[GW3.6K-EHA-G20] GoodWe 3.6kW All In One ESA Hybrid Inverter with Dual Tracker DC & AFCI

GoodWe 3.6kW All In One ESA Hybrid Inverter with Dual Tracker DC & AFCI - Image 2

New!

5 In Stock

GoodWe 3.6kW All In One ESA Hybrid Inverter with Dual Tracker DC & AFCI

Login | Register to see price

GoodWe 3.6kW All In One ESA Hybrid Inverter with Dual Tracker DC & AFCI

The ESA 3–10K Hybrid Inverters sit at the heart of GoodWe’s ESA all-in-one residential storage platform (3–10 kW inverter, 5–48 kWh usable).

Purpose-built for the ESA ecosystem, these single-phase units deliver 3–10 kW to suit typical household loads and operate only with GoodWe BAT5 or BAT8 battery modules.

About the Inverter

3.6 kW single-phase hybrid inverter, 2MPPT
200% PV oversizing
Maximum Input Current per MPPT: 20A
Low start input voltage: 50V
Max European efficiency: 96.5%
Inverter Standard Warranty: 10 years
Commercial extension options: up to 20 years

Backup:

Switching time to backup < 4ms
63A bypass to support for full backup loads
Up to 2 times overload for 10s

Advanced control and communications:

Micro-grid and AC-coupling operations possible
Self-use, ToU, Peak-shaving, and up to 6 smart operation modes
Firmware update with SolarGo App possible
Ready for AI-EMS

Enhanced safety:

AI-driven AFCI 3.0
Inverter with SPD Type II (DC and AC)
Storage 6-layer safety protection
IP66 protection

Compatibility:

GoodWe ESA 3–10K must be installed with GoodWe BAT5 or BAT8 batteries. Mixing 5 kWh and 8 kWh modules in one stack is supported.
Battery-ready (no batteries) is not permitted. ESA inverter and batteries are interdependent and must be commissioned together.

About All-in-One ESA 3-10kW Residential Battery Storage System

Compact, elegantly designed, IP66-rated all-in-one energy storage system that integrates hybrid inverter, LFP battery stack, UPS-grade backup switching, and battery enclosure.

Operates reliably indoors or outdoors in any weather conditions. Pre-wired and modular for fast installation.

Ideal applications:

New builds and retrofits seeking whole-home backup and bill reduction
Homes targeting high self-consumption with large PV arrays
Projects needing capacity growth over time

Power and capacity:

Inverter sizes: 3, 3.6, 5, 6, 8, 10 kW single-phase
Battery modules: 5 kWh or 8 kWh LFP
Scalable storage: 5–48 kWh per system (up to 6 modules per stack)
Mix-and-match old and new battery modules for expansions

Multiple inverter configuration:

Up to 6 inverters (up to 288kWh total storage capacity)
On-grid & Backup parallel possible; AC-coupling scenario supported

Backup and performance:

<4 ms UPS-level switchover (built-in) for whole-home backup
1C charge and discharge for fast cycling

Safety and reliability:

LFP chemistry with high cycle stability
Six-layer safety architecture, including AI-driven arc fault interruption (AFCI 3.0)
Cell- and module-level monitoring

Smart energy features:

Smart home integration with multi-protocol comms
On-grid, off-grid, microgrid and AC-coupled scenarios

Scope of delivery:

Inverter Box: CT 120A/40mA and connection cable; Battery base; Smart dongle; Adjustable feet; Communication cable; Decorative covers; Handles; Anti-tip bracket; PV terminals, AC terminals, other miscellaneous parts.
Battery Box: Battery; Plugs and screws
Smart Meter
“How to Install the ESA 3–10 kW from GoodWe Solar Academy”

[GW3600-DNS-30-AFCI] GoodWe 3.6kW DNS G3 1Ph String Inverter - 2MPPTs, DC & AFCI

GoodWe 3.6kW DNS G3 1Ph String Inverter - 2MPPTs, DC & AFCI - Image 2

3 In Stock

GoodWe 3.6kW DNS G3 1Ph String Inverter - 2MPPTs, DC & AFCI

Login | Register to see price

GoodWe 3kW DNS G3 1Ph String Inverter - 2MPPTs, DC & AFCI

The GoodWe DNS G3 is a single-phase residential inverter engineered for safe, reliable and near-silent operation while maximising energy yield.

Its compact, fanless design suits discreet wall mounting, and its modern, smart-home-ready platform supports flexible system control. With 16 A input current per string, dual MPPTs, the DNS G3 pairs seamlessly with today’s high-power PV modules.

Add GoodWe HomeKit 1000 or GM1000 to enable export limiting and whole-home load monitoring. It delivers high efficiency, robust protection and straightforward app-based monitoring to help homeowners get more from their solar investment.

KEY FEATURES:

Compact and quiet.
3.6 kW, single-phase string inverter with AFCI for enhanced protection.
Dual MPPT architecture: Two independent trackers optimise production across different roof aspects or partial shading.
Supports high-power modules with up to 16 A input current and allows up to 110% AC output.
European efficiency: 97.0%
Low start-up voltage (50V) - for higher energy harvest.
Maximum input voltage: 600V.
Smart home readiness: Works with GoodWe HomeKit 1000 or GM1000 for power export limiting and load monitoring.
Easy monitoring: Built-in Wi-Fi for remote performance tracking and diagnostics via the GoodWe smartphone app.
Safety and durability: IP66 enclosure for dust and water resistance, integrated surge protection.
Tidy indoor or outdoor wall mounting.
Warranty: 10 years.

[GW3600-ES-20-AFCI] GoodWe 3.6kW ES G2 1Ph Hybrid Inverter - 2MPPTs, DC & AFCI

GoodWe 3.6kW ES G2 1Ph Hybrid Inverter - 2MPPTs, DC & AFCI - Image 2

Check Availability

GoodWe 3.6kW ES G2 1Ph Hybrid Inverter - 2MPPTs, DC & AFCI

Login | Register to see price

GoodWe 3.6kW ES G2 1Ph Hybrid Inverter - 2MPPTs, DC & AFCI

The GoodWe ES G2 Series is a new generation of low-voltage single-phase hybrid inverters designed to optimise self-consumption and provide seamless energy management for residential solar systems. Engineered for flexibility and reliability, it enables UPS-level switching to backup mode in under 10 ms, ensuring continuous power for demanding household loads such as air conditioners.

The inverter supports parallel operation for greater backup capacity and integrates intelligent control functions, including smart home compatibility, dry-contact load control, and remote shutdown for enhanced safety.

The ES G2 delivers quick installation, quiet operation, and superior adaptability. Compatible with GoodWe’s Lynx U batteries.

About the Inverter

3.6 kW single-phase hybrid inverter (LV) with 2MPPT
Parallel connection for extended backup capacity
Maximum Input Current per MPPT: 16A
Plug-and-play installation; elegant, compact design
Max European efficiency: 96.7%
UPS-level switching < 10 ms for uninterrupted power
Smart load control and home integration via multi-protocol communication
AFCI protection integrated and remote shutdown
Plug-and-play installation; compact and fanless design
Compatible with GoodWe Lynx U battery and other low-voltage batteries (incl. lead-acid)
IP65 protection for indoor and outdoor use
Wall Mounted
ES G2 + Lynx U G3 qualify for 10 years warranty, once installed by GoodWe Plus+ certified installer. Manual registration is required by installers, more details in https://10year-warranty.semsportal.com/#/

[GW29.9K-ET] GoodWe 30kW 3Ph Hybrid Inverter with DC & AFCI (ET 15-30K)

GoodWe 30kW 3Ph Hybrid Inverter with DC & AFCI (ET 15-30K) - Image 2

2 In Stock

GoodWe 30kW 3Ph Hybrid Inverter with DC & AFCI (ET 15-30K)

Login | Register to see price

GoodWe 30kW 3Ph Hybrid Inverter with DC & AFCI (ET 15-30K)

The GoodWe ET 15–30 kW Series is a powerful three-phase hybrid inverter, designed for residential and commercial systems. The ET Series can be combined with a wide range of battery capacities and brands.

The ET Series also offers a powerful backup performance, capable of delivering up to 36 kVA for 60 seconds. This short-term overload capacity ensures stable operation of high-demand appliances during backup mode.

With integrated DC surge protection and AFCI (Arc-Fault Circuit Interruption), it ensures enhanced electrical safety and fire prevention. Its high-voltage battery interface and UPS-level backup capability ensure a seamless energy supply.

KEY FEATURES:

Maximum efficiency of 97.5%
Modern and compact design
Smart and efficient operations
Powerful back-up with UPS level switching
Parallel connection for larger systems
Peak shaving
IP66 protection
AFCI (optional)
DC Surge Protection Type II
Smart Fan Cooling
Integrated Remote Shutdown

[GW30K-SDT-30-AFCI] GoodWe 30kW SDT G3 3Ph String Inverter - 3 MPPTs, DC & AFCI

GoodWe 30kW SDT G3 3Ph String Inverter - 3 MPPTs, DC & AFCI - Image 2

Check Availability

GoodWe 30kW SDT G3 3Ph String Inverter - 3 MPPTs, DC & AFCI

Login | Register to see price

GoodWe 30kW SDT G3 3Ph String Inverter - 3 MPPTs, DC & AFCI

The SDT G3 25–40 kW series is purpose-built for three-phase commercial and industrial PV systems using modern high-power modules. It accepts high input currents, supports generous DC oversizing and delivers quiet, reliable operation thanks to its fanless, IP66 design.

Optional Type II SPDs on both AC and DC sides, together with Arc Fault Circuit Interrupter 3.0 (AFCI 3.0), raise site safety by detecting arc faults, sending alarms via monitoring and shutting the inverter down when needed.

Note: G99 ENA Certified, document pending

KEY FEATURES:

30 kW, 3-phase, 3 MPPTs for flexible rooftop layouts
AFCI 3.0 for enhanced DC safety with automatic arc detection, alarms and inverter shutdown
High current input for high-power PV modules
Max PV input voltage: 1100 V
European efficiency: up to 98.3%
Supports up to 150% DC oversizing
Supports 110% AC overloading for increased energy yield
Fanless, silent operation for C&I rooftops
IP66 enclosure for outdoor installation
Built-in DC switch
Optional Type II SPD on both DC and AC sides
Anti-islanding and grid protections integrated
Smart energy management
Communication: RS485, WiFi, LAN or 4G or Bluetooth (Optional)
Warranty: 5 Years

[GW30K-SDT-30-DC] GoodWe 30kW SDT G3 3Ph String Inverter - 3 MPPTs, DC (no AFCI)

GoodWe 30kW SDT G3 3Ph String Inverter - 3 MPPTs, DC (no AFCI) - Image 2

Check Availability

GoodWe 30kW SDT G3 3Ph String Inverter - 3 MPPTs, DC (no AFCI)

Login | Register to see price

GoodWe 30kW SDT G3 3Ph String Inverter - 3 MPPTs, DC (No AFCI)

The SDT G3 25–40 kW series is purpose-built for three-phase commercial and industrial PV systems using modern high-power modules. It accepts high input currents, supports generous DC oversizing and delivers quiet, reliable operation thanks to its fanless, IP66 design.

Optional Type II SPDs on both AC and DC sides, together with Arc Fault Circuit Interrupter 3.0 (AFCI 3.0), raise site safety by detecting arc faults, sending alarms via monitoring and shutting the inverter down when needed.

Note: G99 ENA Certified, document pending

KEY FEATURES:

30 kW, 3-phase, 3 MPPTs for flexible rooftop layouts
High current input for high-power PV modules
Max PV input voltage: 1100 V
European efficiency: up to 98.3%
Supports up to 150% DC oversizing
Supports 110% AC overloading for increased energy yield
Fanless, silent operation for C&I rooftops
IP66 enclosure for outdoor installation
Built-in DC switch
Optional Type II SPD on both DC and AC sides
Anti-islanding and grid protections integrated
Smart energy management
Communication: RS485, WiFi, LAN or 4G or Bluetooth (Optional)
Warranty: 5 Years

[GW3K-EHA-G20] GoodWe 3kW All In One ESA Hybrid Inverter with Dual Tracker DC & AFCI

GoodWe 3kW All In One ESA Hybrid Inverter with Dual Tracker DC & AFCI - Image 2

New!

Check Availability

GoodWe 3kW All In One ESA Hybrid Inverter with Dual Tracker DC & AFCI

Login | Register to see price

GoodWe 3kW All In One ESA Hybrid Inverter with Dual Tracker DC & AFCI

The ESA 3–10K Hybrid Inverters sit at the heart of GoodWe’s ESA all-in-one residential storage platform (3–10 kW inverter, 5–48 kWh usable).

Purpose-built for the ESA ecosystem, these single-phase units deliver 3–10 kW to suit typical household loads and operate only with GoodWe BAT5 or BAT8 battery modules.

About the Inverter

3 kW single-phase hybrid inverter, 2MPPT
200% PV oversizing
Maximum Input Current per MPPT: 20A
Low start input voltage: 50V
Max European efficiency: 96.5%
Inverter Standard Warranty: 10 years
Commercial extension options: up to 20 years

Backup:

Switching time to backup < 4ms
63A bypass to support for full backup loads
Up to 2 times overload for 10s

Advanced control and communications:

Micro-grid and AC-coupling operations possible
Self-use, ToU, Peak-shaving, and up to 6 smart operation modes
Firmware update with SolarGo App possible
Ready for AI-EMS

Enhanced safety:

AI-driven AFCI 3.0
Inverter with SPD Type II (DC and AC)
Storage 6-layer safety protection
IP66 protection

Compatibility:

GoodWe ESA 3–10K must be installed with GoodWe BAT5 or BAT8 batteries. Mixing 5 kWh and 8 kWh modules in one stack is supported.
Battery-ready (no batteries) is not permitted. ESA inverter and batteries are interdependent and must be commissioned together.

About All-in-One ESA 3-10kW Residential Battery Storage System

Compact, elegantly designed, IP66-rated all-in-one energy storage system that integrates hybrid inverter, LFP battery stack, UPS-grade backup switching, and battery enclosure.

Operates reliably indoors or outdoors in any weather conditions. Pre-wired and modular for fast installation.

Ideal applications:

New builds and retrofits seeking whole-home backup and bill reduction
Homes targeting high self-consumption with large PV arrays
Projects needing capacity growth over time

Power and capacity:

Inverter sizes: 3, 3.6, 5, 6, 8, 10 kW single-phase
Battery modules: 5 kWh or 8 kWh LFP
Scalable storage: 5–48 kWh per system (up to 6 modules per stack)
Mix-and-match old and new battery modules for expansions

Multiple inverter configuration:

Up to 6 inverters (up to 288kWh total storage capacity)
On-grid & Backup parallel possible; AC-coupling scenario supported

Backup and performance:

<4 ms UPS-level switchover (built-in) for whole-home backup
1C charge and discharge for fast cycling

Safety and reliability:

LFP chemistry with high cycle stability
Six-layer safety architecture, including AI-driven arc fault interruption (AFCI 3.0)
Cell- and module-level monitoring

Smart energy features:

Smart home integration with multi-protocol comms
On-grid, off-grid, microgrid and AC-coupled scenarios

Scope of delivery:

Inverter Box: CT 120A/40mA and connection cable; Battery base; Smart dongle; Adjustable feet; Communication cable; Decorative covers; Handles; Anti-tip bracket; PV terminals, AC terminals, other miscellaneous parts.
Battery Box: Battery; Plugs and screws
Smart Meter
“How to Install the ESA 3–10 kW from GoodWe Solar Academy”

[GW3000-DNS-30-AFCI] GoodWe 3kW DNS G3 1Ph String Inverter - 2MPPTs, DC & AFCI

GoodWe 3kW DNS G3 1Ph String Inverter - 2MPPTs, DC & AFCI - Image 2

4 In Stock

GoodWe 3kW DNS G3 1Ph String Inverter - 2MPPTs, DC & AFCI

Login | Register to see price

GoodWe 3kW DNS G3 1Ph String Inverter - 2MPPTs, DC & AFCI

The GoodWe DNS G3 is a single-phase residential inverter engineered for safe, reliable and near-silent operation while maximising energy yield.

Its compact, fanless design suits discreet wall mounting, and its modern, smart-home-ready platform supports flexible system control. With 16 A input current per string, dual MPPTs, the DNS G3 pairs seamlessly with today’s high-power PV modules.

Add GoodWe HomeKit 1000 or GM1000 to enable export limiting and whole-home load monitoring. It delivers high efficiency, robust protection and straightforward app-based monitoring to help homeowners get more from their solar investment.

KEY FEATURES:

Compact and quiet.
3 kW, single-phase string inverter with AFCI for enhanced protection.
Dual MPPT architecture: Two independent trackers optimise production across different roof aspects or partial shading.
Supports high-power modules with up to 16 A input current and allows up to 110% AC output.
European efficiency: 97.4%
Low start-up voltage (50V) - for higher energy harvest.
Maximum input voltage: 600V.
Smart home readiness: Works with GoodWe HomeKit 1000 or GM1000 for power export limiting and load monitoring.
Easy monitoring: Built-in Wi-Fi for remote performance tracking and diagnostics via the GoodWe smartphone app.
Safety and durability: IP66 enclosure for dust and water resistance, integrated surge protection.
Tidy indoor or outdoor wall mounting.
Warranty: 10 years.

[GW3000-XS-30-AFCI] GoodWe 3kW XS G3 1Ph String Inverter - 1MPPT, DC & AFCI

GoodWe 3kW XS G3 1Ph String Inverter - 1MPPT, DC & AFCI - Image 2

4 In Stock

GoodWe 3kW XS G3 1Ph String Inverter - 1MPPT, DC & AFCI

Login | Register to see price

GoodWe 3kW XS G3 1Ph String Inverter - 1MPPT, DC & AFCI

The GoodWe XS G3 is a compact single-phase inverter for modern homes. It delivers high yields in a lightweight unit and is suitable for indoor or outdoor installation. It supports high-current modules up to 16 A and allows up to 110% AC output.

Natural convection keeps it quiet, and a low start-up voltage helps the inverter begin tracking earlier in the morning and stay online later as array voltage dips.

Quick commissioning via the GoodWe app, SEMS monitoring, smart-home and SG-ready (Smart Grid-ready) compatibility, export limiting, 24-hour load monitoring, and weather-resistant construction make it a reliable fit for single-phase residential systems.

KEY FEATURES:

3kW, single-phase string inverter with AFCI
Ultra-compact and lightweight (4.6 kg)
1 MPPT architecture for simple, cost-effective installs
Supports high-power modules with up to 16 A input current
Low start-up voltage (50V) - for higher energy harvest
European efficiency: 97.1%
10% additional power compared to the nominal output
Silent, fanless operation using natural convection cooling
App-based commissioning and remote monitoring via GoodWe SEMS
Smart home and SG-ready integration
Export-limiting compatibility for UK DNO requirements
IP66 enclosure for indoor or outdoor installation
Surge protection Type III (Type II optional)
Warranty: 10 years

[GW4200-DNS-30-AFCI] GoodWe 4.2kW DNS G3 1Ph String Inverter - 2MPPTs, DC & AFCI

GoodWe 4.2kW DNS G3 1Ph String Inverter - 2MPPTs, DC & AFCI - Image 2

Check Availability

GoodWe 4.2kW DNS G3 1Ph String Inverter - 2MPPTs, DC & AFCI

Login | Register to see price

GoodWe 4.2kW DNS G3 1Ph String Inverter - 2MPPTs, DC & AFCI

The GoodWe DNS G3 is a single-phase residential inverter engineered for safe, reliable and near-silent operation while maximising energy yield.

Its compact, fanless design suits discreet wall mounting, and its modern, smart-home-ready platform supports flexible system control. With 16 A input current per string, dual MPPTs, the DNS G3 pairs seamlessly with today’s high-power PV modules.

Add GoodWe HomeKit 1000 or GM1000 to enable export limiting and whole-home load monitoring. It delivers high efficiency, robust protection and straightforward app-based monitoring to help homeowners get more from their solar investment.

KEY FEATURES:

Compact and quiet.
4.2kW, single-phase string inverter with AFCI for enhanced protection.
Dual MPPT architecture: Two independent trackers optimise production across different roof aspects or partial shading.
Supports high-power modules with up to 16 A input current and allows up to 110% AC output.
European efficiency: 97.2%
Low start-up voltage (50V) - for higher energy harvest.
Maximum input voltage: 600V.
Smart home readiness: Works with GoodWe HomeKit 1000 or GM1000 for power export limiting and load monitoring.
Easy monitoring: Built-in Wi-Fi for remote performance tracking and diagnostics via the GoodWe smartphone app.
Safety and durability: IP66 enclosure for dust and water resistance, integrated surge protection.
Tidy indoor or outdoor wall mounting.
Warranty: 10 years.

[GW40K-ET-10] GoodWe 40kW 3Ph Hybrid Inverter with DC & AFCI

GoodWe 40kW 3Ph Hybrid Inverter with DC & AFCI - Image 2

Check Availability

GoodWe 40kW 3Ph Hybrid Inverter with DC & AFCI

Login | Register to see price

GoodWe 40kW 3Ph Hybrid Inverter with DC & AFCI

The GoodWe ET 40–50 kW Series is a powerful three-phase hybrid inverter designed for commercial and industrial energy storage systems. The ET Series can be paired with a wide range of high-voltage battery capacities and brands.

Its parallel connection capability allows seamless expansion for both on-grid and off-grid setups. When coupled with the Static Transfer Switch (STS) Box, the system supports dependable UPS-level switching to backup mode.

With integrated DC surge protection and AFCI (Arc-Fault Circuit Interruption), it provides enhanced electrical safety and fire prevention. Its high-voltage battery interface and UPS-level backup capability ensure a seamless and reliable energy supply.

KEY FEATURES:

Maximum efficiency of 97.5%
Modern and compact design
Smart and efficient operations
Powerful back-up with STS box
Peak shaving and grid support
Parallel connection for larger systems
3 MPPTs
Max. Input Current per MPPT: 42 / 32 / 42A
Peak shaving
IP66 protection
AFCI (optional)
Surge protection Type 2 on DC side
Smart Fan Cooling
Integrated Remote Shutdown

[GW40K-SDT-30-AFCI] GoodWe 40kW SDT G3 3Ph String Inverter - 4 MPPTs, DC & AFCI

GoodWe 40kW SDT G3 3Ph String Inverter - 4 MPPTs, DC & AFCI - Image 2

Check Availability

GoodWe 40kW SDT G3 3Ph String Inverter - 4 MPPTs, DC & AFCI

Login | Register to see price

GoodWe 40kW SDT G3 3Ph String Inverter - 4 MPPTs, DC & AFCI

The SDT G3 25–40 kW series is purpose-built for three-phase commercial and industrial PV systems using modern high-power modules. It accepts high input currents, supports generous DC oversizing and delivers quiet, reliable operation thanks to its fanless, IP66 design.

Optional Type II SPDs on both AC and DC sides, together with Arc Fault Circuit Interrupter 3.0 (AFCI 3.0), raise site safety by detecting arc faults, sending alarms via monitoring and shutting the inverter down when needed.

Note: G99 Certificate pending

KEY FEATURES:

40 kW, 3-phase, 4 MPPTs for flexible rooftop layouts
AFCI 3.0 for enhanced DC safety with automatic arc detection, alarms and inverter shutdown
High current input for high-power PV modules
Max PV input voltage: 1100 V
European efficiency: up to 97.7%
Supports up to 150% DC oversizing
Supports 110% AC overloading for increased energy yield
Fanless, silent operation for C&I rooftops
IP66 enclosure for outdoor installation
Built-in DC switch
Optional Type II SPD on both DC and AC sides
Anti-islanding and grid protections integrated
Smart energy management
Communication: RS485, WiFi, LAN or 4G or Bluetooth (Optional)
Warranty: 5 Years

[LXD5.0-10] GoodWe 5.0 kWh Lynx D HV LFP Battery Module

GoodWe 5.0 kWh Lynx D HV LFP Battery Module - Image 2

New!

11 In Stock

GoodWe 5.0 kWh Lynx D HV LFP Battery Module

Login | Register to see price

GoodWe 5.0 kWh Lynx D HV LFP Battery Module

The GoodWe Lynx D LXD5.0-10 is a 5 kWh high-voltage lithium iron phosphate (LFP) battery module for residential solar energy storage.

With advanced safety, modular scalability and seamless compatibility with GoodWe hybrid and battery inverters, the Lynx D Series delivers flexible, reliable storage for self-consumption, backup and phased expansion. It pairs high energy density with easy modular installation, fully integrated for a cohesive, space-efficient setup.

Why Choose the GoodWe Lynx D

Modular and stackable: Each LXD5.0-10 provides 5 kWh usable and stacks from 5 kWh to 40 kWh (8 modules). Self-detecting modules speed recognition and commissioning, and new and existing modules can be mixed for easy expansion.
Safety first: LFP cells for chemical and thermal stability, IP66 enclosure, and VDE 2510-50 compliance for protection against dust, water and electrical hazards.
Smart monitoring: Works with GoodWe inverters for remote monitoring, diagnosis and firmware updates. Auto-restart after undervoltage plus dual protection from BMS and DCDC manager.
Cohesive ecosystem: Compatible with GoodWe ET G2, ET Plus+, BT, EH Plus+ and BH inverter series.

Key Features:

Scalable: 5 kWh modules build to 40 kWh (8 total) — up to 4 per stack or two stacks (2×4).
GoodWe-ready: Works with GoodWe hybrid/battery inverters; remote diagnostics & firmware updates via inverter.
Reliable performance: Auto-restart after undervoltage and a built-in DCDC for high efficiency.
Fast installation: Self-detecting modules and plug-and-play wiring speed commissioning.
Durable: IP66 rated for indoor/outdoor use.
Mounting: Floor stack or wall-mount (mounting base/bracket required).
Warranty: Standard 10-year limited warranty.

Lynx D Series - Unboxing (Duration 5:14)

[GW50K-ET-10] GoodWe 50kW 3Ph Hybrid Inverter with DC & AFCI

GoodWe 50kW 3Ph Hybrid Inverter with DC & AFCI - Image 2

Check Availability

GoodWe 50kW 3Ph Hybrid Inverter with DC & AFCI

Login | Register to see price

GoodWe 50kW 3Ph Hybrid Inverter with DC & AFCI

The GoodWe ET 40–50 kW Series is a powerful three-phase hybrid inverter designed for commercial and industrial energy storage systems. The ET Series can be paired with a wide range of high-voltage battery capacities and brands.

Its parallel connection capability allows seamless expansion for both on-grid and off-grid setups. When coupled with the Static Transfer Switch (STS) Box, the system supports dependable UPS-level switching to backup mode.

With integrated DC surge protection and AFCI (Arc-Fault Circuit Interruption), it provides enhanced electrical safety and fire prevention. Its high-voltage battery interface and UPS-level backup capability ensure a seamless and reliable energy supply.

KEY FEATURES:

Maximum efficiency of 97.5%
Modern and compact design
Smart and efficient operations
Powerful back-up with STS box
Peak shaving and grid support
Parallel connection for larger systems
4 MPPTs
Max. Input Current per MPPT: 42 / 32 / 42 / 32A
Peak shaving
IP66 protection
AFCI (optional)
Surge protection Type 2 on DC side
Smart Fan Cooling
Integrated Remote Shutdown

[GW5K-EHA-G20] GoodWe 5kW All In One ESA Hybrid Inverter with Dual Tracker DC & AFCI

GoodWe 5kW All In One ESA Hybrid Inverter with Dual Tracker DC & AFCI - Image 2

New!

5 In Stock

GoodWe 5kW All In One ESA Hybrid Inverter with Dual Tracker DC & AFCI

Login | Register to see price

GoodWe 5kW All In One ESA Hybrid Inverter with Dual Tracker DC & AFCI

The ESA 3–10K Hybrid Inverters sit at the heart of GoodWe’s ESA all-in-one residential storage platform (3–10 kW inverter, 5–48 kWh usable).

Purpose-built for the ESA ecosystem, these single-phase units deliver 3–10 kW to suit typical household loads and operate only with GoodWe BAT5 or BAT8 battery modules.

About the Inverter

5 kW single-phase hybrid inverter, 2MPPT
200% PV oversizing
Maximum Input Current per MPPT: 20A
Low start input voltage: 50V
Max European efficiency: 96.8%
Inverter Standard Warranty: 10 years
Commercial extension options: up to 20 years

Backup:

Switching time to backup < 4ms
63A bypass to support for full backup loads
Up to 2 times overload for 10s

Advanced control and communications:

Micro-grid and AC-coupling operations possible
Self-use, ToU, Peak-shaving, and up to 6 smart operation modes
Firmware update with SolarGo App possible
Ready for AI-EMS

Enhanced safety:

AI-driven AFCI 3.0
Inverter with SPD Type II (DC and AC)
Storage 6-layer safety protection
IP66 protection

Compatibility:

GoodWe ESA 3–10K must be installed with GoodWe BAT5 or BAT8 batteries. Mixing 5 kWh and 8 kWh modules in one stack is supported.
Battery-ready (no batteries) is not permitted. ESA inverter and batteries are interdependent and must be commissioned together.

About All-in-One ESA 3-10kW Residential Battery Storage System

Compact, elegantly designed, IP66-rated all-in-one energy storage system that integrates hybrid inverter, LFP battery stack, UPS-grade backup switching, and battery enclosure.

Operates reliably indoors or outdoors in any weather conditions. Pre-wired and modular for fast installation.

Ideal applications:

New builds and retrofits seeking whole-home backup and bill reduction
Homes targeting high self-consumption with large PV arrays
Projects needing capacity growth over time

Power and capacity:

Inverter sizes: 3, 3.6, 5, 6, 8, 10 kW single-phase
Battery modules: 5 kWh or 8 kWh LFP
Scalable storage: 5–48 kWh per system (up to 6 modules per stack)
Mix-and-match old and new battery modules for expansions

Multiple inverter configuration:

Up to 6 inverters (up to 288kWh total storage capacity)
On-grid & Backup parallel possible; AC-coupling scenario supported

Backup and performance:

<4 ms UPS-level switchover (built-in) for whole-home backup
1C charge and discharge for fast cycling

Safety and reliability:

LFP chemistry with high cycle stability
Six-layer safety architecture, including AI-driven arc fault interruption (AFCI 3.0)
Cell- and module-level monitoring

Smart energy features:

Smart home integration with multi-protocol comms
On-grid, off-grid, microgrid and AC-coupled scenarios

Scope of delivery:

Inverter Box: CT 120A/40mA and connection cable; Battery base; Smart dongle; Adjustable feet; Communication cable; Decorative covers; Handles; Anti-tip bracket; PV terminals, AC terminals, other miscellaneous parts.
Battery Box: Battery; Plugs and screws
Smart Meter
“How to Install the ESA 3–10 kW from GoodWe Solar Academy”

[GW5000-DNS-30-AFCI] GoodWe 5kW DNS G3 1Ph String Inverter - 2MPPTs, DC & AFCI

GoodWe 5kW DNS G3 1Ph String Inverter - 2MPPTs, DC & AFCI - Image 2

Check Availability

GoodWe 5kW DNS G3 1Ph String Inverter - 2MPPTs, DC & AFCI

Login | Register to see price

GoodWe 5kW DNS G3 1Ph String Inverter - 2MPPTs, DC & AFCI

The GoodWe DNS G3 is a single-phase residential inverter engineered for safe, reliable and near-silent operation while maximising energy yield.

Its compact, fanless design suits discreet wall mounting, and its modern, smart-home-ready platform supports flexible system control. With 16 A input current per string, dual MPPTs, the DNS G3 pairs seamlessly with today’s high-power PV modules.

Add GoodWe HomeKit 1000 or GM1000 to enable export limiting and whole-home load monitoring. It delivers high efficiency, robust protection and straightforward app-based monitoring to help homeowners get more from their solar investment.

KEY FEATURES:

Compact and quiet.
5 kW, single-phase string inverter with AFCI for enhanced protection.
Dual MPPT architecture: Two independent trackers optimise production across different roof aspects or partial shading.
Supports high-power modules with up to 16 A input current and allows up to 110% AC output.
European efficiency: 97.3%
Low start-up voltage (50V) - for higher energy harvest.
Maximum input voltage: 600V.
Smart home readiness: Works with GoodWe HomeKit 1000 or GM1000 for power export limiting and load monitoring.
Easy monitoring: Built-in Wi-Fi for remote performance tracking and diagnostics via the GoodWe smartphone app.
Safety and durability: IP66 enclosure for dust and water resistance, integrated surge protection.
Tidy indoor or outdoor wall mounting.
Warranty: 10 years.

[GW5000-ES-20-AFCI] GoodWe 5kW ES G2 1Ph Hybrid Inverter - 2MPPTs, DC & AFCI

GoodWe 5kW ES G2 1Ph Hybrid Inverter - 2MPPTs, DC & AFCI - Image 2

6 In Stock

GoodWe 5kW ES G2 1Ph Hybrid Inverter - 2MPPTs, DC & AFCI

Login | Register to see price

GoodWe 5kW ES G2 1Ph Hybrid Inverter - 2MPPTs, DC & AFCI

The GoodWe ES G2 Series is a new generation of low-voltage single-phase hybrid inverters designed to optimise self-consumption and provide seamless energy management for residential solar systems. Engineered for flexibility and reliability, it enables UPS-level switching to backup mode in under 10 ms, ensuring continuous power for demanding household loads such as air conditioners.

The inverter supports parallel operation for greater backup capacity and integrates intelligent control functions, including smart home compatibility, dry-contact load control, and remote shutdown for enhanced safety.

The ES G2 delivers quick installation, quiet operation, and superior adaptability. Compatible with GoodWe’s Lynx U batteries.

About the Inverter

5 kW single-phase hybrid inverter (LV) with 2MPPT
Parallel connection for extended backup capacity
Maximum Input Current per MPPT: 16A
Plug-and-play installation; elegant, compact design
Max European efficiency: 96.7%
UPS-level switching < 10 ms for uninterrupted power
Smart load control and home integration via multi-protocol communication
AFCI protection integrated and remote shutdown
Plug-and-play installation; compact and fanless design
Compatible with GoodWe Lynx U battery and other low-voltage batteries (incl. lead-acid)
IP65 protection for indoor and outdoor use
Wall Mounted
ES G2 + Lynx U G3 qualify for 10 years warranty, once installed by GoodWe Plus+ certified installer. Manual registration is required by installers, more details in https://10year-warranty.semsportal.com/#/

[GW5000-ES-20-DC] GoodWe 5kW ES G2 Hybrid Inverter with Dual Tracker DC (No AFCI)

Check Availability

GoodWe 5kW ES G2 Hybrid Inverter with Dual Tracker DC (No AFCI)

Login | Register to see price

GoodWe 5kW ES G2 1Ph Hybrid Inverter - 2MPPTs, DC (No AFCI)

The GoodWe ES G2 Series is a new generation of low-voltage single-phase hybrid inverters designed to optimise self-consumption and provide seamless energy management for residential solar systems. Engineered for flexibility and reliability, it enables UPS-level switching to backup mode in under 10 ms, ensuring continuous power for demanding household loads such as air conditioners.

The inverter supports parallel operation for greater backup capacity and integrates intelligent control functions, including smart home compatibility, dry-contact load control, and remote shutdown for enhanced safety.

The ES G2 delivers quick installation, quiet operation, and superior adaptability. Compatible with GoodWe’s Lynx U batteries.

About the Inverter

5 kW single-phase hybrid inverter (LV) with 2MPPT
Parallel connection for extended backup capacity
Maximum Input Current per MPPT: 16A
Plug-and-play installation; elegant, compact design
Max European efficiency: 96.7%
UPS-level switching < 10 ms for uninterrupted power
Smart load control and home integration via multi-protocol communication
AFCI protection integrated and remote shutdown
Plug-and-play installation; compact and fanless design
Compatible with GoodWe Lynx U battery and other low-voltage batteries (incl. lead-acid)
IP65 protection for indoor and outdoor use
Wall Mounted
ES G2 + Lynx U G3 qualify for 10 years warranty, once installed by GoodWe Plus+ certified installer. Manual registration is required by installers, more details in https://10year-warranty.semsportal.com/#/

[GW60KS-MT-EU-AFCI] GoodWe 60kW SMT 3Ph String Inverter - 6 MPPTs, DC & AFCI

GoodWe 60kW SMT 3Ph String Inverter - 6 MPPTs, DC & AFCI - Image 2

Check Availability

GoodWe 60kW SMT 3Ph String Inverter - 6 MPPTs, DC & AFCI

Login | Register to see price

GoodWe 60kW SMT 3Ph String Inverter - 6 MPPTs, DC & AFCI

The GoodWe SMT Series 25–60 kW is built for complex C&I layouts and modern high-power modules. Featuring up to six MPPTs and a wide operating range, the inverters perform consistently across conditions.

The compact, lightweight design makes transport and installation straightforward, while integration with the GoodWe Smart Energy Controller SEC1000 enables load monitoring and export limitation.

KEY FEATURES:

60 kW, 3-phase, 6 MPPTs for multiple orientations and partial shading
AFCI for enhanced DC safety with automatic arc detection, alarms and inverter shutdown
Easy handling with a compact, lightweight chassis
Up to 15 A per string, compatible with high-current PV modules
Max PV input voltage: 1100 V
European efficiency: up to 98.1%
Full power up to 45°C and 110% AC output for longer peak production
Fuse-free design for simpler maintenance and improved reliability
Supports 110% AC overloading for increased energy yield
Export control ready via SEC1000 integration for power export limiting and load monitoring
Ingress protection: IP65
Communication: RS485, WiFi
Type II SPD on DC and AC sides
Remote data monitoring and site management via GoodWe platforms
Warranty: 5 Years

[GW6000-ET-20] GoodWe 6kW 3Ph Hybrid Inverter with Dual Tracker DC & AFCI

Check Availability

GoodWe 6kW 3Ph Hybrid Inverter with Dual Tracker DC & AFCI

Login | Register to see price

GoodWe 6kW 3Ph Hybrid Inverter with Dual Tracker DC & AFCI

The GoodWe ET G2 Series is a powerful three-phase hybrid inverter, designed for residential systems. With dual MPPT trackers, it offers flexible string design high-power PV modules.

The ET G2 delivers UPS-level switching (<10 ms) and supports 100 % unbalanced output in both self-consumption and backup modes. Integrated dynamic power export limit and load monitoring.

With integrated Type II DC and AC surge protection and AFCI (optional), it ensures enhanced electrical safety and fire prevention.

Note: Pending for G98/G99/G100 Certificate

KEY FEATURES:

Maximum efficiency of 97.2%
Lower energy cost
Smart and flexible solutions
Uninterrupted power supply
Integrated smart meter
Smart operation modes
2 MPPTs
IP66 protection
AFCI (optional)
DC Surge Protection Type II
Natural Fan Cooling
Integrated Remote Shutdown

[GW6K-EHA-G20] GoodWe 6kW All In One ESA Hybrid Inverter with Dual Tracker DC & AFCI

GoodWe 6kW All In One ESA Hybrid Inverter with Dual Tracker DC & AFCI - Image 2

New!

6 In Stock

GoodWe 6kW All In One ESA Hybrid Inverter with Dual Tracker DC & AFCI

Login | Register to see price

GoodWe 6kW All In One ESA Hybrid Inverter with Dual Tracker DC & AFCI

The ESA 3–10K Hybrid Inverters sit at the heart of GoodWe’s ESA all-in-one residential storage platform (3–10 kW inverter, 5–48 kWh usable).

Purpose-built for the ESA ecosystem, these single-phase units deliver 3–10 kW to suit typical household loads and operate only with GoodWe BAT5 or BAT8 battery modules.

About the Inverter

6 kW single-phase hybrid inverter, 2MPPT
200% PV oversizing
Maximum Input Current per MPPT: 20A
Low start input voltage: 50V
Max European efficiency: 97.0%
Inverter Standard Warranty: 10 years
Commercial extension options: up to 20 years

Backup:

Switching time to backup < 4ms
63A bypass to support for full backup loads
Up to 2 times overload for 10s

Advanced control and communications:

Micro-grid and AC-coupling operations possible
Self-use, ToU, Peak-shaving, and up to 6 smart operation modes
Firmware update with SolarGo App possible
Ready for AI-EMS

Enhanced safety:

AI-driven AFCI 3.0
Inverter with SPD Type II (DC and AC)
Storage 6-layer safety protection
IP66 protection

Compatibility:

GoodWe ESA 3–10K must be installed with GoodWe BAT5 or BAT8 batteries. Mixing 5 kWh and 8 kWh modules in one stack is supported.
Battery-ready (no batteries) is not permitted. ESA inverter and batteries are interdependent and must be commissioned together.

About All-in-One ESA 3-10kW Residential Battery Storage System

Compact, elegantly designed, IP66-rated all-in-one energy storage system that integrates hybrid inverter, LFP battery stack, UPS-grade backup switching, and battery enclosure.

Operates reliably indoors or outdoors in any weather conditions. Pre-wired and modular for fast installation.

Ideal applications:

New builds and retrofits seeking whole-home backup and bill reduction
Homes targeting high self-consumption with large PV arrays
Projects needing capacity growth over time

Power and capacity:

Inverter sizes: 3, 3.6, 5, 6, 8, 10 kW single-phase
Battery modules: 5 kWh or 8 kWh LFP
Scalable storage: 5–48 kWh per system (up to 6 modules per stack)
Mix-and-match old and new battery modules for expansions

Multiple inverter configuration:

Up to 6 inverters (up to 288kWh total storage capacity)
On-grid & Backup parallel possible; AC-coupling scenario supported

Backup and performance:

<4 ms UPS-level switchover (built-in) for whole-home backup
1C charge and discharge for fast cycling

Safety and reliability:

LFP chemistry with high cycle stability
Six-layer safety architecture, including AI-driven arc fault interruption (AFCI 3.0)
Cell- and module-level monitoring

Smart energy features:

Smart home integration with multi-protocol comms
On-grid, off-grid, microgrid and AC-coupled scenarios

Scope of delivery:

Inverter Box: CT 120A/40mA and connection cable; Battery base; Smart dongle; Adjustable feet; Communication cable; Decorative covers; Handles; Anti-tip bracket; PV terminals, AC terminals, other miscellaneous parts.
Battery Box: Battery; Plugs and screws
Smart Meter
“How to Install the ESA 3–10 kW from GoodWe Solar Academy”

[GW6000-DNS-30-AFCI] GoodWe 6kW DNS G3 1Ph String Inverter - 2MPPTs, DC & AFCI

GoodWe 6kW DNS G3 1Ph String Inverter - 2MPPTs, DC & AFCI - Image 2

4 In Stock

GoodWe 6kW DNS G3 1Ph String Inverter - 2MPPTs, DC & AFCI

Login | Register to see price

GoodWe 6kW DNS G3 1Ph String Inverter - 2MPPTs, DC & AFCI

The GoodWe DNS G3 is a single-phase residential inverter engineered for safe, reliable and near-silent operation while maximising energy yield.

Its compact, fanless design suits discreet wall mounting, and its modern, smart-home-ready platform supports flexible system control. With 16 A input current per string, dual MPPTs, the DNS G3 pairs seamlessly with today’s high-power PV modules.

Add GoodWe HomeKit 1000 or GM1000 to enable export limiting and whole-home load monitoring. It delivers high efficiency, robust protection and straightforward app-based monitoring to help homeowners get more from their solar investment.

KEY FEATURES:

Compact and quiet.
6 kW, single-phase string inverter with AFCI for enhanced protection.
Dual MPPT architecture: Two independent trackers optimise production across different roof aspects or partial shading.
Supports high-power modules with up to 16 A input current and allows up to 110% AC output.
European efficiency: 97.4%
Low start-up voltage (50V) - for higher energy harvest.
Maximum input voltage: 600V.
Smart home readiness: Works with GoodWe HomeKit 1000 or GM1000 for power export limiting and load monitoring.
Easy monitoring: Built-in Wi-Fi for remote performance tracking and diagnostics via the GoodWe smartphone app.
Safety and durability: IP66 enclosure for dust and water resistance, integrated surge protection.
Tidy indoor or outdoor wall mounting.
Warranty: 10 years.

[GW6000-ES-20-AFCI] GoodWe 6kW ES G2 1Ph Hybrid Inverter - 2MPPTs, DC & AFCI

GoodWe 6kW ES G2 1Ph Hybrid Inverter - 2MPPTs, DC & AFCI - Image 2

Check Availability

GoodWe 6kW ES G2 1Ph Hybrid Inverter - 2MPPTs, DC & AFCI

Login | Register to see price

GoodWe 6kW ES G2 1Ph Hybrid Inverter - 2MPPTs, DC & AFCI

The GoodWe ES G2 Series is a new generation of low-voltage single-phase hybrid inverters designed to optimise self-consumption and provide seamless energy management for residential solar systems. Engineered for flexibility and reliability, it enables UPS-level switching to backup mode in under 10 ms, ensuring continuous power for demanding household loads such as air conditioners.

The inverter supports parallel operation for greater backup capacity and integrates intelligent control functions, including smart home compatibility, dry-contact load control, and remote shutdown for enhanced safety.

The ES G2 delivers quick installation, quiet operation, and superior adaptability. Compatible with GoodWe’s Lynx U batteries.

About the Inverter

6 kW single-phase hybrid inverter (LV) with 2MPPT
Parallel connection for extended backup capacity
Maximum Input Current per MPPT: 16A
Plug-and-play installation; elegant, compact design
Max European efficiency: 96.7%
UPS-level switching < 10 ms for uninterrupted power
Smart load control and home integration via multi-protocol communication
AFCI protection integrated and remote shutdown
Plug-and-play installation; compact and fanless design
Compatible with GoodWe Lynx U battery and other low-voltage batteries (incl. lead-acid)
IP65 protection for indoor and outdoor use
Wall Mounted
ES G2 + Lynx U G3 qualify for 10 years warranty, once installed by GoodWe Plus+ certified installer. Manual registration is required by installers, more details in https://10year-warranty.semsportal.com/#/

[GW80K-SMT-AFCI] GoodWe 80kW SMT 3Ph String Inverter - 6 MPPTs, DC & AFCI

GoodWe 80kW SMT 3Ph String Inverter - 6 MPPTs, DC & AFCI - Image 2

Check Availability

GoodWe 80kW SMT 3Ph String Inverter - 6 MPPTs, DC & AFCI

Login | Register to see price

GoodWe 80kW SMT 3Ph String Inverter - 6 MPPTs, DC & AFCI

A robust three-phase 80 kW inverter for commercial rooftops and small ground-mounts. It pairs wide MPPT tracking with 150% DC oversizing, high input current, and built-in protection to deliver strong yields with straightforward installation and low ongoing maintenance.

Designed for UK C&I projects that need reliable performance, clear monitoring, and grid-friendly control.

KEY FEATURES:

80 kW, 3-phase, 6 MPPTs
Up to 120 kW max DC input (150% DC oversizing)
AFCI (3.0) plus DC/AC surge protection for safer operation
Up to 21 A per string, compatible with high-current PV modules
Max PV input voltage: 1100 V
European efficiency: up to 98.1%
Compact, installer-friendly design with quick commissioning and tidy wiring
Ingress protection: IP66
Outdoor-ready enclosure for commercial rooftops and plant rooms
Communication: RS485, WiFi + LAN+Bluetooth
Type II SPD on DC and AC sides
String-level monitoring and remote portal access for fast diagnostics via GoodWe platforms
Warranty: 5 Years

[GW8000-ET-20] GoodWe 8kW 3Ph Hybrid Inverter with Dual Tracker DC & AFCI

Check Availability

GoodWe 8kW 3Ph Hybrid Inverter with Dual Tracker DC & AFCI

Login | Register to see price

GoodWe 8kW 3Ph Hybrid Inverter with Dual Tracker DC & AFCI

The GoodWe ET G2 Series is a powerful three-phase hybrid inverter, designed for residential systems. With dual MPPT trackers, it offers flexible string design high-power PV modules.

The ET G2 delivers UPS-level switching (<10 ms) and supports 100 % unbalanced output in both self-consumption and backup modes. Integrated dynamic power export limit and load monitoring.

With integrated Type II DC and AC surge protection and AFCI (optional), it ensures enhanced electrical safety and fire prevention.

Note: Pending for G98/G99/G100 Certificate

KEY FEATURES:

Maximum efficiency of 97.2%
Lower energy cost
Smart and flexible solutions
Uninterrupted power supply
Integrated smart meter
Smart operation modes
2 MPPTs
IP66 protection
AFCI (optional)
DC Surge Protection Type II
Natural Fan Cooling
Integrated Remote Shutdown

[GW8K-EHA-G20] GoodWe 8kW All In One ESA Hybrid Inverter with Dual Tracker DC & AFCI

GoodWe 8kW All In One ESA Hybrid Inverter with Dual Tracker DC & AFCI - Image 2

New!

1 In Stock

GoodWe 8kW All In One ESA Hybrid Inverter with Dual Tracker DC & AFCI

Login | Register to see price

GoodWe 8kW All In One ESA Hybrid Inverter with Dual Tracker DC & AFCI

The ESA 3–10K Hybrid Inverters sit at the heart of GoodWe’s ESA all-in-one residential storage platform (3–10 kW inverter, 5–48 kWh usable).

Purpose-built for the ESA ecosystem, these single-phase units deliver 3–10 kW to suit typical household loads and operate only with GoodWe BAT5 or BAT8 battery modules.

About the Inverter

8 kW single-phase hybrid inverter, 2MPPT
200% PV oversizing
Maximum Input Current per MPPT: 20A
Low start input voltage: 50V
Max European efficiency: 96.8%
Inverter Standard Warranty: 10 years
Commercial extension options: up to 20 years

Backup:

Switching time to backup < 4ms
63A bypass to support for full backup loads
Up to 2 times overload for 10s

Advanced control and communications:

Micro-grid and AC-coupling operations possible
Self-use, ToU, Peak-shaving, and up to 6 smart operation modes
Firmware update with SolarGo App possible
Ready for AI-EMS

Enhanced safety:

AI-driven AFCI 3.0
Inverter with SPD Type II (DC and AC)
Storage 6-layer safety protection
IP66 protection

Compatibility:

GoodWe ESA 3–10K must be installed with GoodWe BAT5 or BAT8 batteries. Mixing 5 kWh and 8 kWh modules in one stack is supported.
Battery-ready (no batteries) is not permitted. ESA inverter and batteries are interdependent and must be commissioned together.

About All-in-One ESA 3-10kW Residential Battery Storage System

Compact, elegantly designed, IP66-rated all-in-one energy storage system that integrates hybrid inverter, LFP battery stack, UPS-grade backup switching, and battery enclosure.

Operates reliably indoors or outdoors in any weather conditions. Pre-wired and modular for fast installation.

Ideal applications:

New builds and retrofits seeking whole-home backup and bill reduction
Homes targeting high self-consumption with large PV arrays
Projects needing capacity growth over time

Power and capacity:

Inverter sizes: 3, 3.6, 5, 6, 8, 10 kW single-phase
Battery modules: 5 kWh or 8 kWh LFP
Scalable storage: 5–48 kWh per system (up to 6 modules per stack)
Mix-and-match old and new battery modules for expansions

Multiple inverter configuration:

Up to 6 inverters (up to 288kWh total storage capacity)
On-grid & Backup parallel possible; AC-coupling scenario supported

Backup and performance:

<4 ms UPS-level switchover (built-in) for whole-home backup
1C charge and discharge for fast cycling

Safety and reliability:

LFP chemistry with high cycle stability
Six-layer safety architecture, including AI-driven arc fault interruption (AFCI 3.0)
Cell- and module-level monitoring

Smart energy features:

Smart home integration with multi-protocol comms
On-grid, off-grid, microgrid and AC-coupled scenarios

Scope of delivery:

Inverter Box: CT 120A/40mA and connection cable; Battery base; Smart dongle; Adjustable feet; Communication cable; Decorative covers; Handles; Anti-tip bracket; PV terminals, AC terminals, other miscellaneous parts.
Battery Box: Battery; Plugs and screws
Smart Meter
“How to Install the ESA 3–10 kW from GoodWe Solar Academy”

[GW5.1-BAT-D-20] GoodWe All-In-One ESA 5.12kWh Battery Module

GoodWe All-In-One ESA 5.12kWh Battery Module - Image 2

New!

16 In Stock

GoodWe All-In-One ESA 5.12kWh Battery Module

Login | Register to see price

GoodWe All-In-One ESA 5.12kWh Battery Module

GoodWe’s ESA residential storage platform combines 5 kWh or 8 kWh battery modules - mixing sizes in one system is supported - with 3–10 kW inverters, enabling 5–48 kWh of usable storage.

ESA inverter and batteries are interdependent and must be commissioned together.
The LiFePO4 battery modules provide fast, safe, and flexible storage for modern homes.

About the Battery

Usable Energy: 5kWh
LiFePO4 (LFP) technology
Scalability: Up to 6 battery modules
Maintains full 1C charge/discharge in cold conditions, giving faster cycling than most competitor systems
Integrated DCDC converter in each battery module
Operating Voltage Range (single-phase): 350~550 V
Peak output power (7.5 kW/10s)
Charging Temperature Range: -18~55 (°C)
6-layer storage safety protection
Fire suppression and heating as standard
Floor and Wall mounting possible
Certification: EC62619, IEC60730, EN62477, CE, RCM, N38.3 ADR
IP66
Warranty: 10 years

About All-in-One ESA 3-10kW Residential Battery Storage System

Compact, elegantly designed, IP66-rated all-in-one energy storage system that integrates hybrid inverter, LFP battery stack, UPS-grade backup switching, and battery enclosure.

Operates reliably indoors or outdoors in any weather conditions. Pre-wired and modular for fast installation.

Ideal applications:

New builds and retrofits seeking whole-home backup and bill reduction
Homes targeting high self-consumption with large PV arrays
Projects needing capacity growth over time

Power and capacity:

Inverter sizes: 3, 3.6, 5, 6, 8, 10 kW single-phase
Battery modules: 5.12 kWh or 8.32 kWh LFP
Scalable storage: 5–48 kWh per system (up to 6 modules per stack)
Mix-and-match old and new battery modules for expansions

Multiple inverter configuration:

Up to 6 inverters (up to 288kWh total storage capacity)
On-grid & Backup parallel possible; AC-coupling scenario supported

Backup and performance:

<4 ms UPS-level switchover (built-in) for whole-home backup
1C charge and discharge for fast cycling

Safety and reliability:

LFP chemistry with high cycle stability
Six-layer safety architecture, including AI-driven arc fault interruption (AFCI 3.0)
Cell- and module-level monitoring

Smart energy features:

Smart home integration with multi-protocol comms
On-grid, off-grid, microgrid and AC-coupled scenarios

Scope of delivery:

Inverter Box: CT 120A/40mA and connection cable; Battery base; Smart dongle; Adjustable feet; Communication cable; Decorative covers; Handles; Anti-tip bracket; PV terminals, AC terminals, other miscellaneous parts.
Battery Box: Battery; Plugs and screws
Smart Meter
“How to Install the ESA 3–10 kW from GoodWe Solar Academy”

GoodWe ESA 3–10 K | Next-Generation All-in-One Residential Storage System (Duration 1:46)

[GW8.3-BAT-D-20] GoodWe All-In-One ESA 8.32kWh Battery Module

GoodWe All-In-One ESA 8.32kWh Battery Module - Image 2

New!

2 In Stock

GoodWe All-In-One ESA 8.32kWh Battery Module

Login | Register to see price

GoodWe All-In-One ESA 8.32kWh Battery Module

GoodWe’s ESA residential storage platform combines 5 kWh or 8 kWh battery modules - mixing sizes in one system is supported - with 3–10 kW inverters, enabling 5–48 kWh of usable storage.

ESA inverter and batteries are interdependent and must be commissioned together.
The LiFePO4 battery modules provide fast, safe, and flexible storage for modern homes.

About the Battery

Usable Energy: 8kWh
LiFePO4 (LFP) technology
Scalability: Up to 6 battery modules
Maintains full 1C charge/discharge in cold conditions, giving faster cycling than most competitor systems
1C charge/discharge rate possible at low temp. environments
Integrated DCDC converter in each battery module
Operating Voltage Range (single-phase): 350~550 V
Peak output power (12 kW/10s)
Charging Temperature Range: -18~55 (°C)
6-layer storage safety protection
Fire suppression and heating as standard
Floor and Wall mounting possible
Certification: EC62619, IEC60730, EN62477, CE, RCM, N38.3 ADR
IP66
Warranty: 10 years

About All-in-One ESA 3-10kW Residential Battery Storage System

Compact, elegantly designed, IP66-rated all-in-one energy storage system that integrates hybrid inverter, LFP battery stack, UPS-grade backup switching, and battery enclosure.

Operates reliably indoors or outdoors in any weather conditions. Pre-wired and modular for fast installation.

Ideal applications:

New builds and retrofits seeking whole-home backup and bill reduction
Homes targeting high self-consumption with large PV arrays
Projects needing capacity growth over time

Power and capacity:

Inverter sizes: 3, 3.6, 5, 6, 8, 10 kW single-phase
Battery modules: 5.12 kWh or 8.32 kWh LFP
Scalable storage: 5–48 kWh per system (up to 6 modules per stack)
Mix-and-match old and new battery modules for expansions

Multiple inverter configuration:

Up to 6 inverters (up to 288kWh total storage capacity)
On-grid & Backup parallel possible; AC-coupling scenario supported

Backup and performance:

<4 ms UPS-level switchover (built-in) for whole-home backup
1C charge and discharge for fast cycling

Safety and reliability:

LFP chemistry with high cycle stability
Six-layer safety architecture, including AI-driven arc fault interruption (AFCI 3.0)
Cell- and module-level monitoring

Smart energy features:

Smart home integration with multi-protocol comms
On-grid, off-grid, microgrid and AC-coupled scenarios

Scope of delivery:

Inverter Box: CT 120A/40mA and connection cable; Battery base; Smart dongle; Adjustable feet; Communication cable; Decorative covers; Handles; Anti-tip bracket; PV terminals, AC terminals, other miscellaneous parts.
Battery Box: Battery; Plugs and screws
Smart Meter
“How to Install the ESA 3–10 kW from GoodWe Solar Academy”

GoodWe ESA 3–10 K | Next-Generation All-in-One Residential Storage System (Duration 1:46)

[GM330] GoodWe GM330 3-Phase Smart Energy Meter

Check Availability

GoodWe GM330 3-Phase Smart Energy Meter

Login | Register to see price

GoodWe| Alternergy

GoodWe GM330 3-Phase Smart Energy Meter

The GoodWe GM330 is a three-phase smart energy meter designed for accurate monitoring of grid import and export in solar PV systems. It enables real-time energy measurement and supports export limitation when used with compatible GoodWe inverters.

Compact and DIN-rail mountable, the GM330 weighs approximately 0.2 kg and is suitable for residential and commercial installations. It provides precise energy data to optimise system performance and enhance energy management.

KEY FEATURES:

Three-phase smart energy meter for accurate grid monitoring
Measures both energy import and export
Supports export limitation with compatible GoodWe inverters
Real-time energy data monitoring
High accuracy metering (0.5% class)
Compact DIN-rail mount design
Suitable for residential and commercial installations
Lightweight construction (approx. 0.2 kg)
Reliable and durable build quality
IP20 rating (indoor)
Dimension (W/D/H): 72/72/85mm

[Base for LXD G1] GoodWe Lynx D Floor Base

6 In Stock

GoodWe Lynx D Floor Base

Login | Register to see price

GoodWe Lynx D Floor Base

Provides a secure floor-mounting solution for GOODWE Lynx Home D Storage System. Up to 4 battery modules can be stacked per ground base. A second base is required for 5 or more modules.

Dimensions (H x W x D): 40 x 700 x 170 mm.

[LXD G1 Project Hanger] GoodWe Lynx D Wall Bracket

Check Availability

GoodWe Lynx D Wall Bracket

Login | Register to see price

GoodWe Lynx D wall bracket

Provides a secure wall-mounting solution for GOODWE Lynx Home D Storage System. Up to 4 battery modules can be stacked per wall mount. A second wall mount is required for 5 or more modules.

Dimensions (H x W x D): 120x 700 x 170 mm.

[GW-LX U5.0-30] GoodWe Lynx U G3 Series, LX U5.0-30, Low Voltage Battery

GoodWe Lynx U G3 Series, LX U5.0-30, Low Voltage Battery - Image 2

New!

Check Availability

GoodWe Lynx U G3 Series, LX U5.0-30, Low Voltage Battery

Login | Register to see price

GoodWe Lynx U G3 Series, LX U5.0-30, Low Voltage Battery

The GoodWe Lynx U G3 Series is a low-voltage residential battery system designed for safe, flexible and efficient home energy storage. Its compact, modular construction allows fast installation and easy integration for both self-consumption and backup applications.

Each module includes its own built-in BMS, removing the need for an external power control unit and simplifying commissioning.

As a low-voltage, scalable solution, it can be expanded to 150 kWh through up to 30 parallel modules, making it suitable for a wide range of residential storage needs. With remote diagnostics, and seamless compatibility with GoodWe hybrid inverter ranges, the Lynx U G3 provides homeowners with long-term resilience and installers with a straightforward, future-proof battery solution.

Why Choose the GoodWe Lynx U G3 Series

Key Features:

Nominal Battery Energy: 5.12 kWh
Scalable: 5 kWh modules build to 150 kWh (30 units in parallel)
90A charge / 100A discharge capability
Operating Voltage Range: 43.2~58.24 V
Built-in BMS (no external PCU required
Fire suppression and heating as standard
Plug-and-play installation with pre-wired communication cables
LFP (lithium iron phosphate) technology for enhanced safety and long lifespan
Remote monitoring, diagnostics and auto-reboot
IP65-rated for indoor and outdoor installation
Wall or floor-mounted installation
Compatible with GoodWe ES hybrid inverters
ES G2 + Lynx U G3 qualify for 10 years warranty, once installed by GoodWe Plus+ certified installer. Manual registration is required by installers, more details in https://10year-warranty.semsportal.com/#/

Lynx U G3 Series - How to install (Duration 4:56)

[Ezlink3000] GoodWe Smart Dongle EZLink 3000

New!

10 In Stock

GoodWe Smart Dongle EZLink 3000

Login | Register to see price

GoodWe Smart Dongle EZLink 3000

Ezlink3000 is a compact, lightweight communication device that connects compatible inverters to GoodWe’s Smart Energy Management System (SEMS) for reliable data monitoring. With flexible installation options and support for both WiFi and LAN, it’s designed for easy deployment, indoors or outdoors, even in demanding environmental conditions.

Key features:

Compact size and lightweight design
Flexible installation for a variety of sites and layouts
WiFi and LAN connectivity options
Connects inverters to GoodWe SEMS for monitoring and data logging
Supports inverter paralleling function (for compatible models)
Outdoor-capable design for harsh conditions
Wide operating tolerance for temperature and humidity
Bluetooth Communication: Bluetooth 5.1
Dimensions (WxHxD): 48 x 153 x 32 mm
IP65

[GW-ESA-CARRY HANDLE] Goodwe Battery Lifting Accessory (Pair)

Goodwe Battery Handler.webp

5 In Stock

Goodwe Battery Lifting Accessory (Pair)

Login | Register to see price

Goodwe Battery Lifting Accessory (Pair)

This accessory provides safe lifting, handling, and installation of GoodWe All-In-One battery systems. It provides installers with a secure grip point, helping to reduce the risk of injury and preventing damage to the battery unit during transport and positioning.

The lifting handles are compatible with both batteries and inverters.

[HC-U4G] Haier 4G Communication Module

16 In Stock

Haier 4G Communication Module

Login | Register to see price

Haier 4G Communication Module

The Haier HC-U4G Communication Module, designed for Smart Cube Energy Controllers. This USB module enables reliable 4G communication for remote monitoring and system control. IP66-rated for safe indoor and outdoor use.

KEY FEATURES:

Support 4G communication
IP66 protection rating
Plug & play, easy to use
Support 4G: FDD-LTE / TDD-LTE
USB Connection Interface
Dimensions(W / H / D): 52 / 112 / 33 mm

[InsK-G] Haier Installation Kit for Ground-mounted

Haier Installation Kit for Ground-mounted - Image 2

Check Availability

Haier Installation Kit for Ground-mounted

Login | Register to see price

Haier Installation Kit for Ground-mounted

The Haier InsK-G installation kit is designed for ground mounting of the Smart Cube Energy Storage System. It is suitable for configurations combining one inverter (controller) with up to six battery modules.

[InsK-W] Haier Installation Kit for Wall-mounted

5 In Stock

Haier Installation Kit for Wall-mounted

Login | Register to see price

Haier Installation Kit for Wall-mounted

The Haier InsK W installation kit is designed for wall mounting of the Smart Cube Energy Storage system. It is suitable for configurations combining one inverter (controller) with up to two battery modules.

[HBP-5.0-A] Haier Smart Cube 5kWh Battery Module With LED

Haier Smart Cube 5kWh Battery Module With LED - Image 2

7 In Stock

Haier Smart Cube 5kWh Battery Module With LED

Login | Register to see price

Haier Smart Cube 5kWh Battery With LED

The Haier Smart Cube Battery is a key component of the Haier Smart Cube 6-in-1 Energy Storage System. This all-in-one ESS seamlessly integrates a PV inverter, Battery Power Conversion System (PCS), EV DC Charge

The Haier Smart Cube battery system features a modular and stackable design, allowing for flexible capacity expansion to meet a wide range of energy storage needs. It is suitable for both residential and commercial applications and supports on-grid and off-grid scenarios, making it a versatile solution for different energy setups.

Each stack can hold up to six battery modules, with the option to mix 5kWh and compatible 8kWh units. For larger installations, up to 20 stacks - totalling 120 battery modules - can be connected in parallel, enabling a maximum system capacity of 960kWh.

KEY FEATURES:

Available capacity: 5.2 kWh battery
LiFePO4 technology (280Ah cell)
1 to 6 batteries per stack (max 30kWh)
Max. 20 stacks in parallel
Installation is quick and uncomplicated. Batteries are simply stacked on top of each other with no additional assembly is required
DOD: 100% (under test conditions)
Max. charging and discharging power: 2,500W
Peak discharge / charge power of 3,750W
Service life: > 7000 cycles
Full temperature monitoring
Multi-layer full battery safety protection
15 mins stackable installation
5 mins fast commissioning
AI assisted energy planning, safety protection, VPP scheduling, and service support
Instantaneous 0 ms backup switching
Smart Cube app function
IP66 protection rating
The battery needs a Smart Cube Energy Controler to work
Any combination of HBP-5.0 and HBP-8.0 battery modules can be used with the Haier Smart Cube EC.
Mixing Smart Cube batteries with those from other manufacturers is not supported.
10-year product warranty and 10-year performance warranty

[HBP-8.0-A] Haier Smart Cube 8kWh Battery Unit With LED

Haier Smart Cube 8kWh Battery Unit With LED - Image 2

8 In Stock

Haier Smart Cube 8kWh Battery Unit With LED

Login | Register to see price

Haier Smart Cube 8kWh Battery With LED

The Haier Smart Cube Battery is a key component of the Haier Smart Cube 6-in-1 Energy Storage System. This all-in-one ESS seamlessly integrates a PV inverter, Battery Power Conversion System (PCS), EV DC Charger for electric vehicles, Battery Pack, and Energy Management System (EMS).

The Haier Smart Cube battery system features a modular and stackable design, allowing for flexible capacity expansion to meet a wide range of energy storage needs. It is suitable for both residential and commercial applications and supports on-grid and off-grid scenarios, making it a versatile solution for different energy setups.

Each stack can hold up to six battery modules, with the option to mix 5kWh and compatible 8kWh units. For larger installations, up to 20 stacks - totalling 120 battery modules - can be connected in parallel, enabling a maximum system capacity of 960kWh.

KEY FEATURES:

Available capacity: 7.8 kWh battery
LiFePO4 technology (280Ah cell)
1 to 6 batteries per stack (max 30kWh)
Max. 20 stacks in parallel
Installation is quick and uncomplicated. Batteries are simply stacked on top of each other with no additional assembly is required
DOD: 100% (under test conditions)
Max. charging and discharging power: 4,000W
Peak discharge / charge power of 6,000W
Service life: > 7000 cycles
Full temperature monitoring
Multi-layer full battery safety protection
15 mins stackable installation
5 mins fast commissioning
AI assisted energy planning, safety protection, VPP scheduling, and service support
Instantaneous 0 ms backup switching
Smart Cube app function
IP66 protection rating
The battery needs a Smart Cube Energy Controler to work
Any combination of HBP-5.0 and HBP-8.0 battery modules can be used with the Haier Smart Cube EC.
Mixing Smart Cube batteries with those from other manufacturers is not supported.
10-year product warranty and 10-year performance warranty

[HH1P-3.6K-A] Haier Smart Cube HH1P-3.6K, 3.6kW, 1Ph , Hybrid Inverter

Haier Smart Cube HH1P-3.6K, 3.6kW, 1Ph , Hybrid Inverter - Image 3

4 In Stock

Haier Smart Cube HH1P-3.6K, 3.6kW, 1Ph , Hybrid Inverter

Login | Register to see price

Haier Smart Cube HH1P-3.6K, 3.6kW, 1Ph, Hybrid Inverter

Battery Connection:

Compatible Battery Models: HBP-5.0 (5kWh) and HBP-8.0 (8kWh)
Number of Batteries per Inverter (controller): 1 ~ 6 – Max 48kWh per inverter
Up to 20 systems in parallel
Batteries can be mixed and matched

The Haier Smart Cube Energy Controller is a key part of the AI-optimised Smart Cube 6-in-1 Energy Storage System, combining a hybrid inverter, EV DC charger, heat pump, battery, and EMS into one powerful solution. It delivers a first-class, all-in-one way to harness solar energy in both residential and commercial buildings.

The Haier Smart Cube is optimised for on-grid and hybrid applications, including PV + ESS, battery-ready setups, retrofits, EV charging, heat pump integration, and backup power.

Read more

While its main strength is in grid-connected scenarios, limited off-grid operation may be possible depending on system design.

The unique design of the Haier Smart Cube ESS is accentuated by its elegant modern aesthetic, including a sleek front panel and ambient side lighting, allowing it to blend effortlessly into any environment. The system delivers energy independence with exceptional efficiency, cost savings, flexibility, and resilience.

The accompanying app gives customers a clear and stylish overview of energy consumption anytime, anywhere.
Haier appliance owners gain the added bonus of connecting their Haier home devices with the Smart Cube system for intelligent energy management. Otherwise, the Smart Cube functions as a complete standalone solution.

KEY FEATURES:

Dual MPP trackers
Integrated BMS
DC ground-fault protection
Maximum Input Current per MPPT: 16A
DC/AC ratio up to 2.0
Ingress protection: IP66
Natural air cooling
Display and LED light strip: side ambient lighting
Communication: WLAN, Ethernet, RS485, Communication Module (4G/3G/2G)
The Smart Cube controller needs at least one Battery HBP-5.0 or HBP-8.0 to work
10-year warranty

[HH1P-3K-A] Haier Smart Cube HH1P-3K, 3.0kW, 1Ph, Hybrid Inverter

Haier Smart Cube HH1P-3K, 3.0kW, 1Ph, Hybrid Inverter - Image 3

2 In Stock

Haier Smart Cube HH1P-3K, 3.0kW, 1Ph, Hybrid Inverter

Login | Register to see price

Haier Smart Cube HH1P-3K, 3.0kW, 1Ph, Hybrid Inverter

Battery Connection:

Compatible Battery Models: HBP-5.0 (5kWh) and HBP-8.0 (8kWh)
Number of Batteries per Inverter (controller): 1 ~ 6 – Max 48kWh per inverter
Up to 20 systems in parallel
Batteries can be mixed and matched

The Haier Smart Cube Energy Controller is a key part of the AI-optimised Smart Cube 6-in-1 Energy Storage System, combining a hybrid inverter, EV DC charger, heat pump, battery, and EMS into one powerful solution. It delivers a first-class, all-in-one way to harness solar energy in both residential and commercial buildings.

The Haier Smart Cube is optimised for on-grid and hybrid applications, including PV + ESS, battery-ready setups, retrofits, EV charging, heat pump integration, and backup power.

Read more

While its main strength is in grid-connected scenarios, limited off-grid operation may be possible depending on system design.

The unique design of the Haier Smart Cube ESS is accentuated by its elegant modern aesthetic, including a sleek front panel and ambient side lighting, allowing it to blend effortlessly into any environment. The system delivers energy independence with exceptional efficiency, cost savings, flexibility, and resilience.

The accompanying app gives customers a clear and stylish overview of energy consumption anytime, anywhere.
Haier appliance owners gain the added bonus of connecting their Haier home devices with the Smart Cube system for intelligent energy management. Otherwise, the Smart Cube functions as a complete standalone solution.

KEY FEATURES:

Dual MPP trackers
Integrated BMS
DC ground-fault protection
Maximum Input Current per MPPT: 16A
DC/AC ratio up to 2.0
Ingress protection: IP66
Natural air cooling
Display and LED light strip: side ambient lighting
Communication: WLAN, Ethernet, RS485, Communication Module (4G/3G/2G)
The Smart Cube controller needs at least one Battery HBP-5.0 or HBP-8.0 to work
10-year warranty

[HH1P-5K-A] Haier Smart Cube HH1P-5K, 5.0kW, 1Ph, Hybrid Inverter

Haier Smart Cube HH1P-5K, 5.0kW, 1Ph, Hybrid Inverter - Image 3

6 In Stock

Haier Smart Cube HH1P-5K, 5.0kW, 1Ph, Hybrid Inverter

Login | Register to see price

Haier Smart Cube HH1P-5K, 5.0kW, 1Ph, Hybrid Inverter

Battery Connection:

Compatible Battery Models: HBP-5.0 (5kWh) and HBP-8.0 (8kWh)
Number of Batteries per Inverter (controller): 1 ~ 6 – Max 48kWh per inverter
Up to 20 systems in parallel
Batteries can be mixed and matched

The Haier Smart Cube Energy Controller is a key part of the AI-optimised Smart Cube 6-in-1 Energy Storage System, combining a hybrid inverter, EV DC charger, heat pump, battery, and EMS into one powerful solution. It delivers a first-class, all-in-one way to harness solar energy in both residential and commercial buildings.

The Haier Smart Cube is optimised for on-grid and hybrid applications, including PV + ESS, battery-ready setups, retrofits, EV charging, heat pump integration, and backup power.

Read more

While its main strength is in grid-connected scenarios, limited off-grid operation may be possible depending on system design.

The unique design of the Haier Smart Cube ESS is accentuated by its elegant modern aesthetic, including a sleek front panel and ambient side lighting, allowing it to blend effortlessly into any environment. The system delivers energy independence with exceptional efficiency, cost savings, flexibility, and resilience.

The accompanying app gives customers a clear and stylish overview of energy consumption anytime, anywhere.
Haier appliance owners gain the added bonus of connecting their Haier home devices with the Smart Cube system for intelligent energy management. Otherwise, the Smart Cube functions as a complete standalone solution.

KEY FEATURES:

Dual MPP trackers
Integrated BMS
DC ground-fault protection
Maximum Input Current per MPPT: 16A
DC/AC ratio up to 2.0
Ingress protection: IP66
Natural air cooling
Display and LED light strip: side ambient lighting
Communication: WLAN, Ethernet, RS485, Communication Module (4G/3G/2G)
The Smart Cube controller needs at least one Battery HBP-5.0 or HBP-8.0 to work
10-year warranty

[HH1P-6K-A] Haier Smart Cube HH1P-6K, 6.0kW, 1Ph, Hybrid Inverter

Haier Smart Cube HH1P-6K, 6.0kW, 1Ph, Hybrid Inverter - Image 3

5 In Stock

Haier Smart Cube HH1P-6K, 6.0kW, 1Ph, Hybrid Inverter

Login | Register to see price

Haier Smart Cube HH1P-6K, 6.0kW, 1Ph, Hybrid Inverter

Battery Connection:

Compatible Battery Models: HBP-5.0 (5kWh) and HBP-8.0 (8kWh)
Number of Batteries per Inverter (controller): 1 ~ 6 – Max 48kWh per inverter
Up to 20 systems in parallel
Batteries can be mixed and matched

The Haier Smart Cube Energy Controller is a key part of the AI-optimised Smart Cube 6-in-1 Energy Storage System, combining a hybrid inverter, EV DC charger, heat pump, battery, and EMS into one powerful solution. It delivers a first-class, all-in-one way to harness solar energy in both residential and commercial buildings.

The Haier Smart Cube is optimised for on-grid and hybrid applications, including PV + ESS, battery-ready setups, retrofits, EV charging, heat pump integration, and backup power.

Read more

While its main strength is in grid-connected scenarios, limited off-grid operation may be possible depending on system design.

The unique design of the Haier Smart Cube ESS is accentuated by its elegant modern aesthetic, including a sleek front panel and ambient side lighting, allowing it to blend effortlessly into any environment. The system delivers energy independence with exceptional efficiency, cost savings, flexibility, and resilience.

The accompanying app gives customers a clear and stylish overview of energy consumption anytime, anywhere.
Haier appliance owners gain the added bonus of connecting their Haier home devices with the Smart Cube system for intelligent energy management. Otherwise, the Smart Cube functions as a complete standalone solution.

KEY FEATURES:

Dual MPP trackers
Integrated BMS
DC ground-fault protection
Maximum Input Current per MPPT: 16A
DC/AC ratio up to 2.0
Ingress protection: IP66
Natural air cooling
Display and LED light strip: side ambient lighting
Communication: WLAN, Ethernet, RS485, Communication Module (4G/3G/2G)
10-year warranty

[HX284934] HookStop Shock Absorbing Tile - pack of 6

HookStop Shock Absorbing Tile - pack of 6 - Image 2

130 In Stock

HookStop Shock Absorbing Tile - pack of 6

Login | Register to see price

HookStop | Alternergy

HookStop Shock Absorbing Tile

Put an end to broken tiles

HookStop® is a patented, shock-absorbing tile that replaces the fragile tiles directly under the roof hook. It puts an end to broken tiles, reduces installation time, and gives you peace of mind.

The product eliminates the problem of installers standing on the mounting rail and the downward flexing of the roof hook cracking the roof tile.

FEATURES:

Up to 50% faster
Fits all Plain and Rosemary tiles
Long-lasting outdoor use
UV Stable Recycled Grade R900 Rubber
Dimensions(WxLxH in mm):165 x 248 x 10
10-year warranty

Packed 6 per sheet.

[Huawei LUNA2000-5kwh-BMU] Huawei LUNA2000 S0 BMS (for 5kWh Battery)

Huawei LUNA2000 S0 BMS (for 5kWh Battery) - Image 2

10 In Stock

Huawei LUNA2000 S0 BMS (for 5kWh Battery)

Login | Register to see price

Huawei LUNA2000 S0 BMS (for 5kWh Battery)

This BMS unit (LUNA2000-5KW-C0) is only for use within a Huawei LUNA2000 system.

The modular Huawei LUNA2000 system is a high voltage battery solution which is compatible with a wide range of self-consumption inverters including single and three-phase inverters.

The system primarily targets the residential PV market but it can also be used in small commercial applications.

The modular system consists of a block containing the BMS and battery units which are stackable together offering 5, 10 and 15kWh storage options.This allows for easy, flexible and quick installation.

The LUNA2000 system also allows for parallel connection of up to 30kWh.

LUNA2000 FEATURES:

Compact size and easy installation
High energy density and efficiency
Excellent safety of LiFePO4 battery
Parallel connection: max 6 pack
10 Years warranty

[SUN2000-100KTL-M2 AFCI] Huawei SUN2000 100KTL-M2 AFCI 3ph Inverter

Huawei SUN2000 100KTL-M2 AFCI 3ph Inverter - Image 2

1 In Stock

Huawei SUN2000 100KTL-M2 AFCI 3ph Inverter

Login | Register to see price

Huawei SUN2000 100KTL-M2 AFCI 3ph Inverter

Huawei integrates the latest digital and internet technology in the new FusionSolar Smart PV solution portfolio. The wide range of SUN2000 inverters helps you on any commercial rooftop for maximal efficiency.

Huawei SUN2000 100KTL-M2 three-phase inverter with 10 MPPTs ensures safe, efficient and reliable management of your photovoltaic system, which are combined with a series of technical features that make it among the smartest large size inverters on the market.

Smart:

Smart I-V curve diagnosis: implements the I-V scan and integrity diagnosis for the PV strings. In this way, potential risks and failures can be detected in time
Support AFCI & Smart String Level Disconnector
20V PV Strings

Safety:

Integrated DC switch, safe and convenient component even during maintenance
Residual current monitoring unit: immediately disconnects from the mains after detecting that the residual current exceeds the threshold
Design without fuses

Reliable:

Natural convection cooling technology
IP66 protection degree: it can be installed both indoors and outdoors, away from flammable materials and not under direct sunlight
Type II surge arresters for both DC and AC
Standard 5 year manufacturer warranty can be extended

This inverter must be commissioned either by using the SUN2000 App on your phone or by connecting to the Smart Logger.

[SUN2000-20K-MB0] Huawei SUN2000 20K-MB0 3ph Hybrid Optimiser Inverter

Huawei SUN2000 20K-MB0 3ph Hybrid Optimiser Inverter - Image 2

OUT OF STOCK

Huawei SUN2000 20K-MB0 3ph Hybrid Optimiser Inverter

Login | Register to see price

Huawei SUN2000 20K-MB0 3ph Hybrid Optimiser Inverter

The Huawei SUN2000-20K-MB0 is a battery ready three-phase Optimiser inverter which is ideal for the integration with LUNA Smart String Power Storage System, Smart Optimisers, SmartGuard, and EMMA - Huawei's Energy Management Assistant. The integration ensures an uninterrupted power supply during outages and emergencies.

In a three-phase backup solution, one inverter can control up to four ESS stacks (towers), with storage capacity dependent on the selected LUNA battery model.

KEY FEATURES:

Light and compact 3ph inverter
Power: 20,000 W
2 independent MPPTs
Compatible with residential & MERCS PV Optimisers
Compatible batteries: Huawei LUNA2000 S0 / S1
Communication via RS485; WLAN/Ethernet via Smart Dongle-WLAN-FE (optional), 4G / 3G / 2G via Smart Dongle-4G (optional); EMMA (optional)
Quick installation and easy commissioning with the FusionSolar App
Integrated AFCI protection
Type II AC and DC surge protection
IP66 protection
Product Warranty: 10 years

[SUN2000-25K-MB0] Huawei SUN2000 25K-MB0 3ph Hybrid Optimiser Inverter

Huawei SUN2000 25K-MB0 3ph Hybrid Optimiser Inverter - Image 2

1 In Stock

Huawei SUN2000 25K-MB0 3ph Hybrid Optimiser Inverter

Login | Register to see price

Huawei SUN2000 25K-MB0 3ph Hybrid Optimiser Inverter

The Huawei SUN2000-25K-MB0 is a battery ready three-phase inverter which is ideal for the integration with LUNA Smart String Power Storage System, Smart Optimiser, SmartGuard, and EMMA - Huawei's Energy Management Assistant. The integration ensures an uninterrupted power supply during outages and emergencies.

In a three-phase backup solution, one inverter can control up to four ESS stacks (towers), with storage capacity dependent on the selected LUNA battery model.

KEY FEATURES:

Light and compact 3ph inverter
Power: 25,000 W
2 independent MPPTs
Compatible with residential & MERCS PV Optimisers
Compatible batteries: Huawei LUNA2000 S0 / S1
Communication via RS485; WLAN/Ethernet via Smart Dongle-WLAN-FE (optional), 4G / 3G / 2G via Smart Dongle-4G (optional); EMMA (optional)
Quick installation and easy commissioning with the FusionSolar App
Integrated AFCI protection
Type II AC and DC surge protection
IP66 protection
Product Warranty: 10 years

[HUA-Smart DongleA-05 (AP+STA)] Huawei WLAN-FE Dongle, WLAN or Ethernet or Hotspot

1 In Stock

Huawei WLAN-FE Dongle, WLAN or Ethernet or Hotspot

Login | Register to see price

Huawei WLAN-FE Dongle, WLAN or Ethernet or Hotspot

The Huawei Smart Dongle A-05 (AP+STA) is a communication accessory designed for Huawei solar inverters. With plug-and-play installation via USB, it can connect to up to 10 inverters, ensuring efficient system monitoring. It supports both WLAN and Fast Ethernet connections.

KEY FEATURES:

Plug & Play - Support max. 10 devices
Supports WLAN & Fast Ethernet (FE) and 3rd-party monitoring system communication
Support data encryption for transmission, ensuring data safety
Operating temperature range :–30°C to +65°C
Dimensions (W x H x D) : 146 mm x 48 mm x 33 mm
IP rating: IP65
2 years warranty

Note: This item is also compatible with SUN2000-30/36/40KTL-M3 inverters.

[IMO - SI16-PEL64R-2] IMO 16A DC Isolator - 2 Pole (Single String) IP66 Enclosed, 800 VDC

53 In Stock

IMO 16A DC Isolator - 2 Pole (Single String) IP66 Enclosed, 800 VDC

Login | Register to see price

IMO | Alternergy

IMO 16A DC Isolator - 2 Pole (Single string) IP66 Enclosed, 800 VDC

FEATURES:

2 Pole (1 string)
16A 800 VDC
IP66 Enclosure
Grey Body with Black switch
Switching times of less than 5ms
IMO patented "Safelock" function
Dimensions (mm):180x98x107

IMO Solar Isolators (SI) are specifically designed to interrupt the DC/AC Inverter from the solar panel array. Photovoltaic installations have to be equipped with DC Isolators in accordance with IEC 60364-7-712.

[IMO - SI16-PEL64R-4] IMO 16A DC Isolator - 4 Pole (Two Strings) IP66 Enclosed, 800 VDC

226 In Stock

IMO 16A DC Isolator - 4 Pole (Two Strings) IP66 Enclosed, 800 VDC

Login | Register to see price

IMO | Alternergy

IMO 16A DC Isolator - 4 Pole (Two Strings) IP66 Enclosed, 800 VDC

FEATURES:

4 Pole (2 string)
16A 800VDC
IP66 Enclosure
Grey Body with Black switch
Switching times of less than 5ms
IMO patented "Safelock" function
Dimensions (mm):180x98x107

IMO Solar Isolators (SI) are specifically designed to interrupt the DC/AC Inverter from the solar panel array. Photovoltaic installations have to be equipped with DC Isolators in accordance with IEC 60364-7-712.
