Dunext Commercial Battery Storage

Dunext PowerHill P100-215kWh Battery Storage with DC Coupling Technology


AVAILABLE TO ORDER

Dunext PowerHill commercial storage is an all-in-one, pre-assembled storage solution which is designed for quick connection and commissioning saving time and costs.
The plug-and-play system delivers flexible energy capacity for various uses, including backup power, grid services, and energy cost reduction. It suits a wide range of C&I installations including but not limited to factories, warehouses, supermarkets, charging stations, and farms.

Learn more

Need more help?


Unsure about key battery storage terminology?

View our A–Z Battery Storage Glossary
[Dunext-EMS] Dunext EMS Data management Check Availability
Dunext EMS Data management
Login | Register to see price

Dunext | Alternergy

Dunext EMS Data management


EMS box is used for data information display, storage and operation control of energy storage system. It is a lightweight on-site control and energy management system, which is mainly used for the application scenarios of battery energy storage equipment. Through the application of the system, it can achieve the role of on-site multi-storage equipment power distribution, multi-energy (loads, photovoltaic, wind power, generators, etc.) complementary monitoring and energy management.

Technical Specifications :

  • Controlling function: Peak shaving, Backup mode, Smooth PV output
  • Communication Protocol Ethernet: Modbus-TCP
  • Dimensions (WxHxD): 320×500×60 mm
  • Installation Method: Indoor, hanging
[PowerHill P100-215kWh-5Y] Dunext PowerHill P100-215kWh Battery Storage - 5Y Warranty Dunext PowerHill 215kWh Right90.webp Check Availability
Dunext PowerHill P100-215kWh Battery Storage - 5Y Warranty
Login | Register to see price

Dunext | Alternergy

Dunext PowerHill P100-215kWh Battery Storage - One-Cabinet System per Site

Dunext PowerHill 215kWh battery + 100 kW AC Inverter + 5-year warranty


Dunext PowerHill P100-215kWh commercial and industrial energy battery storage is an all-in-one, pre-assembled system designed for quick connection and commissioning saving time and operating costs.
The plug-and-play system delivers flexible energy capacity for various uses, including backup power, grid services, and energy cost reduction. It suits a wide range of C&I installations including but not limited to factories, warehouses, supermarkets, charging stations, and farms.
The system charges/discharges energy within a 2-hour period (0.5C Rate), allows for flexible scalability, and supports both AC-Coupled and DC-Coupled installations.

It comes with a standard 5-Year Warranty - extendable to 10 years, and short delivery lead times (to be confirmed with Dunext).



Learn More About Dunext PowerHill P100-215 (click to expand/close)

FEATURES: (click to expand/close)

✔  Supports Different C&I Scenarios
  • Multi Application: Self-Consumption, Arbitrage, Peak Shaving & Load Shifting, Backup Function, Off-Grid
  • It supports On-Grid connection, On/Off Grid Switching , Pure Off-Grid with Diesel Generator.
✔  Expandable and Robust
  • The system can be scaled up to 6 battery cabinets connected in parallel with the max 1.29MWh battery capacity.
  • The PowerHill cabinet is designed for outdoor installation, provides an IP55 protection level against dust and water jets from all directions.
  • The cabinet can resist fire for at least 1-hour.
✔  All-in-One Design, Easy Installation and Maintenance
  • Integral prefabricated installation with only 5 cables wiring.
  • Shipment of full packages
✔  Pre-Assembled System

PowerHill is an outdoor battery cabinet with integrated PCS, 12 battery packs (LFP), BMS, fire protection system, air conditioning system, and optional MPPT.

✔  Optimised Thermal Management Design

Two air-conditioners with independent ventilation design make the internal temperature No More Than 35℃ and temperature difference <4℃.

✔  Cooling Method: Forced Air-cooling System
✔  Comprehensive Safety Features
  • The Dunext PowerHill system has five layers of protection: overcharge, short-circuit, overheating, mechanical, and over-discharge.
  • Fire Suppression System: Combustible Gas Detection + Novec1231 (Perfluorohexane fire extinguishing device), with water fire fighting joint as the last barrier.
✔  Communication and Management Capabilities
  • Intelligent O&M Cloud platform DuLink.
    The DuLink App can be downloaded from Google Play and Apple Store.
  • Communication Interface RS485, Ethernet; Communication Protocol: Modbus RTU
✔  Certification Standards

The system complies to widely recognised standards: CE (IEC 61000, IEC 62477), IEC 62619, UN 3480, G99, G100; Battery cell: UL9549A, UL1973.


TECHNICAL INFORMATION:

Cabinet, Battery, and PCS

Cabinet

  • Rated ESS capacity: 215 kWh
  • Depth of Discharge:100% (in testing conditions)
  • Charge/discharge power:100kW
  • IP 55
  • Operating Temperature [℃]: -20 ~ 50
  • Communication Protocol: Modbus RTU
  • System Dimension (WxHxD): 1686 x 2093 x 1354 mm
  • Weight: ≤ 2.5 tonnes
  • Standard 5-Year Warranty (10-Year Option Available)

Battery (DC)

  • Cell Material: LFP
  • Rated battery capacity: 280Ah / 17.92kWh
  • Rated Voltage: 64V
  • Battery String Configuration: 1P20S
  • System Dimension (WxHxD): 378 x 260 x 985 mm
  • Weight: 150kg

PCS (AC)

  • Max. output power 100kW
  • AC voltage and Frequency: 380 / 400 V (3P4W),50 / 60 Hz
  • Rated AC Output: 144A
  • AC current harmonics THDi ≤ 3.0 %

MPPT

  • Rated PV input power: 120kWp
  • PV input oversize: 120%
  • Max PV input current: 200A



PowerHill Series Installation Video (Duration 6:27)

[PowerHill P50-215kWh-MPPT-EMS-10] Dunext PowerHill P50-215kWh Battery + 50 kW AC Inverter - 10 year warranty Check Availability
Dunext PowerHill P50-215kWh Battery + 50 kW AC Inverter - 10 year warranty
Login | Register to see price

Dunext | Alternergy

Dunext PowerHill P50-215kWh Commercial Battery + 50kW AC Inverter - 10Y Warranty


All-in-on solution, charge/ discharge power:

  • 50kW, rated capacity
  • 215kWh Battery Pack
  • Integrated PCS
  • BMS, FFS, HVAC, etc
  • 0.5C
  • 400Vac output
  • 10 years warranty
  • Includes EMS and 120kWp MPPT
Showing 3 of 3 results
