Kipp & Zonen SMP10-A Smart Pyranometer with 4-20mA output
The SMP10 is a spectrally flat Class A pyranometer that combines the sensor technology from the CMP 11, the Smart interface from SMP11 and the low maintainance from the CMP10.
The SMP10 has an internal drying cartridge that will last for at least 10 years if the housing is not opened. This minimises maintainance significantly. The interval for dome cleaning can be extended, and the quality of measurements maximised, by fitting SMP10 with the CVF4 ventilation.
The SMP10 has Modbus® interface, amplified analogue output, improved response time and temperature corrected measurement data. The wide and low power supply range from 5 to 30 VCD makes intergration in meteorological and solar energy stations easy. The SMP10 is protected against over voltage, reversed polarity and short circuiting.
Thanks to the standardized output and connections of every SMP10, exchanging instruments for recalibration is easy.
SmartExplorer Windows™ software for data logging, display of data and Modbus® address setting is provided as standard.
Note: First image shows the product with the mount sun screen.
KEY FEATURES:
- ISO 9060 spectrally flat Class A
- No change of desiccant for 10 years
- RS-485 Modbus® communication
- 5-year warranty
- 4-20mA output
| Accessory By Type | Environmental Sensors or Monitoring and Control |
| Brand | Kipp & Zonen |
