Emlite 3-Phase generation meter EMP 100A (1000 pulse/kWh)
The Emlite EMP1 three phase metering range offers high quality accurate meters that are suitable for direct connected domestic, commercial, Solar PV and light industrial applications.
The EMP1.AV is an entry model of the metering range but it’s of solid high quality construction and benefits from features normally found in more expensive metering brands.
This is a one pulsed output model; it can provide data for collection by an energy management system or AMR data logger. These pulses are output via the meter ’s auxiliary terminals. The output conforms to IEC 62053 -31.
KEY FEATURES:
- Three Phase 100A Rated
- Nominal Voltage: 3 x 230V
- Compact modern design
- Clear easy to read 8 digit LCD with specific symbols for different quantities
- 4 quadrant power measurement (Import and Export, Active and Reactive Energy)
- Optional Power Quality Information – Volts, Current, Power etc.
- Optical communications port
- Accuracy Class A or B (MID) [active energy] and Cl 2 [reactive energy]
- Fully MID approved
- Includes extended terminal cover
- Solid brass terminals
- Pulsed output
- IP54 Protection
| Brand | Emlite |
| Accessory Phase | Three Phase |
| Accessory By Type | Generation Meters |
